Ftth 1 Ge Port Epon Onu - China

We are engaged in manufacturing and exporting excellent quality FTTH 1

GE 1 Port EPON ONU in Shenzhen, Guangdong, China.

Special features:

•Plug and play, features auto- detecting, auto- configuration, and auto firmware upgrade, etc.

•Integrated OAM remote configuration and maintenance function.

•Support rich QinQ VLAN functions and IGMP Snooping multicast features.

•Functions like transceiver diagnostic monitoring, transmitter disable, etc.

•Fully compatibility with OLT based on Broadcom/ PMC/ Cortina chipset.

Upstream PON interface 1 EPON interface, SC single- mode/ single- fibre, symmetric 1.25 Gbps

Wavelength Tx 1310nm, Rx 1490nm

Optical interface SC connector

Downstream LAN interface 1 10/ 100/ 1000Mbps auto adaptive Ethernet interfaces, Full Duplex/ Half Duplex, RJ45 connectors

Indicators 4 indicators, for status of power supply, PON port and 1 Giga- Ethernet port.

DC power supply +12V, external AC- DC power adaptor

Power switch 1

Power consumption ≤5W

Operating condition

Operating temp: - 5~+55℃

Operating humidity: 10~90% ( non- condensed)

Dimension 160mm* 115mm* 32mm( length* width* height)

Net weight 0.24Kg

Ordering Information

HZW- E801 1* EPON( 1490nm , 1310nm , 20Km, SC) , 1* 10/ 100/ 100Base- T, 12V
