Gepon Onu 4 Port 10 100m 3 Fxo Fxs 1 Catv Wireless Routing Interfaces - China

it is a equipment used in PON networking system to provide data for 4

port 10/100M +3 port POTS(FXO/FXS)+1 port CATV 1 10/100M port (VOIP

management port) +1 wireless routing interfaces service.

this EPON ONU products fully comply with IEEE 802.3-2005 and the China Telecom EPON device technical specification (V2.1).

It is operative, manageable and maintainable at telecommunication level, Is a compatible with 802.11b / g wireless routers and VoIP phones EPON HGU (home gateway) device, to provide broadband connectivity to provide users with data, voice, video and other services, and high-speed wireless home and office network connection, suitable for home and business use of the network environment is a multi-service operators to launch a portal.

Product features:

Conform to IEEE802.3ah standard and meet CTC V2.1 technical requirements

Support Ethernet service layer 2 switching and wire-speed forwarding of uplink and downlink services

Support frame filtering and suppression

Support standard 802.1Q Vlan function, support VLAN conversion

Support 4094 VLANs (802.1Q)

Support Dynamic Bandwidth Allocation (DBA) function

Support QoS, including traffic flow classification, priority marking, queue and dispatch, traffic shaping and traffic control, etc

Support IGMP Snooping

Support Ethernet port ratelimit loop detection

Support lightning protection for power supply and lightning protection for service port

VoIP support SIP/H.

248 soft-switching protocol Powerful QoS capabilities, multi-service environment to protect VoIP, IPTV and other business-critical Quality of Service

Support power failure alarm

wireless parameters:

Support Standard: IEEE 802.11b / g, rate: 54Mbps, the maximum number of access capacity of 13 -

CATV radio frequency feature (optional)

Output level 85dBuv (input-6dbm)

AGC working range 10dB CNR =46dB@-6dBm (input)

Port features:

1 PON ports (1.25G)

4 10/100M port

1 CATV port(E8027U have this interface)

2 FXS port

1 FXO port

1 10/100M port (VOIP management port)

1 wireless routing interfaces.

Power supply

5VDC

Power Consumption: <=10 Watts

Environment condition

Operating temperature: 0C~+50 C

Storage temperature: -20 C~+70 C

Relative temperature: 95% (uncondensed)

Dimension

283mm(L)

148mm(W)

30mm(H)
