Cc2530 High Power Zigbee Module - China

Function • RF/layout –Adapt to the 2.4-GHz IEEE 802.15.4 RF transceiver

–High receiver sensitivity and robustness –Programmable output power up

to 21 dBm –Only power Can communicate –16-mm × 28-mm Stamps package

–Suitable for system configuration in line with the worldwide radio

frequency Rate regulations: ETSI EN 300 328 and EN 300440 (Europe), FCC

CFR47 Part 15 (U.S.) And ARIB STD-T-66 (Japan) • Low power consumption

–Active Mode RX (CPU Idle): 27 mA –Active Mode TX 20dBm CPU

Idle : 166mA –Power mode 1 (4 μs wake-up): 0.2 mA

–Power mode 2(Sleep timer running): 1 μA –Power mode 3 (external

interrupt): 0.4 μA –Wide supply voltage range (2 V-3.6 V) •

Microcontrollers –Excellent performance and low power code prefetch

function consumption of 8051 microcontroller core –32, 64 -, 128, 256-KB

system programmable flash -8-KB RAM, has number holding capacity under

variety of power supply –Support for hardware debugging · Default

firmware –Provide transparent serial, frame format ， Various

operating parameters can be configured using the configuration tool, the

user can apply do not program • Peripherals –Powerful 5-channel DMA

–IEEE 802.5.4 MAC timer, general-purpose timer (A 16-bit timer, an 8-bit

timer) –IR generation circuit –32-kHz sleep timer with capture

functionality –Hardware support CSMA/CA –Support accurate digitization

RSSI/LQI –Battery monitor and temperature sensor –7 inputs and

configurable resolution 12-bit ADC –AES Security coprocessor – 2

Powerful USART supports a variety of serial communications protocol –18

general I / O pins (17 × 4 mA, 20 mA) –Watchdog Timer • Development Tool

–CC2530 development kit –CC2530ZigBee®developm ent kit –For the RF4CE

CC2530 RemoTI ™ Development Kit –SmartRF™ software –Packet sniffer

–Available IAR Embedded Workbench Application • 2.4-GHz IEEE 802.15.4

system • RF4CE Remote control systems (greater than 64-KB Flash) •

ZigBee system 256-KB flash • Home / building automation •

lighting system • Industrial control and monitoring • Low-power wireless

sensor networks • Consumer electronics • Healthcare

1 Description CC2530 is a true system-on-chip(SoC)

solution for IEEE 802.15.4, ZigBee and RF4CE applications.

It can be

very low total cost of materials to create a strong network of nodes.

The CC2530 combines the excellent performance of the leading RF

transceiver, the industry-standard enhanced 8051 CPU, system

programmable flash, 8-KB RAM and many other powerful features.

CC2530 have

four different types of flash memory version:

CC2530F32/64/128/256 ，Each having

32/64/128/256 KB flash。CC2530 has a

different mode of operation, the system makes

it especially adapted to the requirements of

the ultra-low power。The conversion between

the run mode in a short time, to further

ensure low energy consumption.

CC2530F256

combined with the gold unit of Texas

Instruments, the industry-leading ZigBee

protocol stack (Z-Stack ™), provides a

powerful and complete ZigBee solution。

CC2530F64 combinaed of Texas Instruments the

gold unit RemoTI, better to provide a

powerful and complete ZigBee RF4CE remote

control solutions。

GB2530 is the wireless module which using

CC2530 and CC2591, has a small, peripheral

simple, easy to use and excellent RF

performance, leads to all external ports, and

the convenience of the user, eliminating the

need for debugging RF as well as other

aspects of the complicated work more

convenient embedded into the system and

shorten the development cyclefaster to seize

market opportunities and cost advantages.

This integrated circuit may be ESD damage.

Note electrostatic protection in use or the

welding process.

Texas Instruments recommends

that all integrated circuits have appropriate

preventive measures to be addressed.

Failure

to observe proper handling and installation

procedures can cause damage.

ESD damage can

range from subtle performance degradation to

complete equipment failure.

Precision

integrated circuits may be more susceptible

to damage because very small parametric

changes could cause the device not to meet

its published specifications.

CC2530 high power zigbee module

Please inquiry for your need now
