Sell Explosion Proof Lcd Monitor - China

BTM Ex- proof LCD monitor is applied in zone 1 and zone 2, group IIA,

IIB, IIC areas

Ex mark : ExdⅡ BT6

Protection class : IP65

General:

Used in the hazard areas with explosive gas

Excellent LCD display

Input AV or VGA signal

Good physical design saves space

Compact shape, easy to transport and operate Visual angle can be adjusted

Protection class IP65

Take consideration of keeping it away from the raining Specification:

BTM series explosion proof LCD monitor products are specially designed for the industrial use.

The explosion proof design makes the monitor work well in the hazard areas.

There are the sizes 15″ , 17″ , 19″ in options

With VGA interface and standard video interfaces, Both NTSC and PAL modes are valid

Display screen is specially designed , it is firm enough, and the screen displays well.

Easy for installation and maintains, put it on the smooth surface or locate it on the frames.

Physical data:

Material cast aluminum , stainless steel 304

Weight 25Kg, 35kg

Exterior size 460( L) x 336( H) x 220( W) mm

Display screen’s thickness 12mm

Screen size 306 x 230mm

Outlet cable holes 2

Outlet cable size G- 3/ 4”

Technical data:

Input voltage DC12V / AC220V , 50/ 60Hz

Current ≤ 3A

Input signals 75Ω / 1Vp- p composite video signals or RGB simulation signals

Contrast ratio: 550 : 1

Brightness 400cd / m2

Display resolution: 1024 * 768， 1280* 768， 1440* 900.

Environment:

Atmospheric pressure: 86～ 106KPa

Ambient temperature: - 30℃ ~+60℃

Relative humidity: ≤ 95% RH( +25℃ )
