Arm 11 6410 Development Board Single Computer - China

CPU： Samsung S3C6410X, ARM1176JZF- S, Frequency 667M

Mobile DDR SDRAM： 128MB~512MB, Mobile DDR SDRAM

FLASH： 1GB NAND FLASH

LCD interface： Accessing to TFT, STN screen from 3.5

to 12.1- inch, standard TFT 7’( 800* 480) screen.

Touch screen： Four- line resistance

TV OUT： One, composite video signal output,

accessing to kindsof TV

TV IN： One, composite video signal input

S- VIDEO interface： One, S- VIDEO video signal output

WIFI interface： One, built- in, accordance with

802.11 b/ g

GPS module： One, global positioning

VGA interface： One, Standard VGA output interface

Audio： One AC97, wolf’s WM9713

USB HOST： One USB HOST interface, adopting the

restoration ofself- insurance protection device to protect

the external power system

USB OTG： One, USB 2.0 HS OTG

Serial port： Four serial ports, baud rate as high as

115200bps

IRDA： One IRDA infrared data communication port

Ethernet port： One 10M/ 100M Ethernet port, DM9000,

with connection andtransmission indicator lights

HS MMC interface： One high- speed SD card interface,

compatible ofSD/ MMC/ MMC4.0 cards

SD card interface： One ordinary SD card interface

CF card interface： One , standard CF R3.0

Camera interface： A 2mm- pitch double- socket for

camera expansion; theusers may use this expansion slot to

connect other models

Keyboard： 3 external interrupt button, 5 scan

button, 1five- direction switch

EEPROM： Two 12C interfaces: 24C08, 24C128

JTAG interface： standard 20- chip Multi- ICE JTAG

interface , supportingthe debugging of ADS1.2, SDT2.51, etc

RTC clock： Internal real- time clock ( with the back-

up lithiumbattery)

LED： Power supply and several indicator lights

Reset circuit： combining the manual reset and chip

reset; the chip isMAX811; the reset is stable and reliable

Expansion interface： Lead to the signal which users

need, including the bus, interrupt, I/ O signals, and so on

Power interface： 12V power supply, with power switch

and indicator light
