19 Inch High Performance Industrial Panel Display 1280 X 1024 Pixels With 5 Wire Touchscreen - China

SunPc technology Co.

LTD provide 8.4', 10.4', 12.1', 15', 17', 19'

industiral panel PC and 8.4', 10.4', 12.1', 15', 17' 19' industrial

touch LCD monitor

19' High Performance Industrial Panel PC

1 - 19' XGA TFT LCD Panel support 1280 × 1024pixels

2 - Intel Core i7/i5/i3/Pentium/Celeron CPU in 1155-pin

3 - Front 6mm aluminum bezel with IP65 compliant

4 - Front hardness glass protect screen

5 - 4* COM, 1* LPT, 1*HDMI, 1*DVI, 1 * VGA, 4 * USB, 1* GLAN, 1* LINE-IN, 1* LINE-OUT

6 - 1* Mini PCIe slot,

7 - Wireless LAN with antenna (option)

8 - Panel ( Flush ) mount with clips

TFT Characteristics

Display Type

19XGA TFT LCD

Pixel Number

1280 x 1024

Pixel Pitch(RGB)

0.297*0.297

Contrast Ratio

1300: 1

Light Intensity

350 nits

Viewable Angles

150°(H), 135°(V)

Max Colors

16.2MB

Response Time

8 ms

MTBF

50, 000hrs.

System Characteristics

Processor

Intel Core i7/i5/i3/Pentium/Celeron CPU In 1555-pin

Chipset

Intel Q57

Memory

2x SO DIMM DDR31066/1333 SDRAM UP to 16GB.

Graphic

On CPU

Storage

Space for 1x2.5' SATA HDD / SSD/ 1 compact flash card slot

Audio

Realtek ALC662, 5.1 Channel surround Audio

USB Port

4 x USB2.0

Ethernet

100/1000M Ethernet

VGA Port

1 x VGA Connector

DVI/HDMI

1 x DVI, 1 x HDMI

Serial Port

4 x COM ( 3 x RS232, 1 x RS232/422/485)

Expansive Slot

1 x PCI, 1 x Mini PCIe

LPT

1 x LPT

Watchdog Timer

255Levels, 1-255sec.

Available Options

Touch Screen

5 Wire Resistive type

Wireless LAN

Meet IEEE802.11b/gstandard.




DC Power Input

DC8-28V

Speakers

2

I/O Connector

HDMI/DVI

1 x HDMI, 1 x DVI

Lan

1 x 100/1000 Lanport(RJ-45))

VGA

1 x VGA

USB

4 x COM(3 x RS232, 1 x RS232/422/485)

Power Switch

1 x Power Switch

DCInput

1 x Lockable DC Input connector

1 x Lin-in/Lin-out/Mic-in

Mechanical and Environmental

Construction

Aluminum front bazel and steel enclosure

Storage humidity

10% to 90% non-condensing

Operating temperature

32°F~125°F(0°C to 50°C)

Anti-Vibration

17 to 500Hz 1G PTP

Storage temperature

-4°F~140°F(-20°C to 60°C)

Dimensions(WxHxD

432x 346 x 80.6 mm

Anti-Shock

1g/peak(11ms)

Weight

Net: 6KG , Volume Gross: 8.5 KG

Power Specification

Input

100~240VAC, 50/60Hz

Output

DC19V@10A/190W, external ACPower Adapter with Lockable connector

Certificate&Approvals

CE/FCC/ROHS

Ordering Information

IPPC-Q190D-2RH

19 'XGA Slim Line Panel Mount Industrial Panel PC, Support intel Core i7/i5/i3/Pentium/Celeron CPU, with 320G HDD, 2G DDR3 RAM, DC19V power adapter

IPPC-Q190DT-2RH

19'XGA Slim Line Panel Mount Industrial Panel PC, Support intel Core i7/i5/i3/Pentium/Celeron CPU, with 19” touch screen, with 320G HDD, 2G DDR3 RAM, DC19V power adapter

Company Contact:

• Posted By: Shenzhen SUNPC Technology Co. Ltd

• Phone: 0086-15817403301

• Address: Xin Ange Building, Bao an Seven District, , Shenzhen , China

• Email:

• Website: http://www.sun-ppc.com

• Business Description: Shenzhen SUNPC technology Co.

  LTD is a high tech manufacturer of

  industrial computer hardwares.

  The headquarters located in in Shenzhen

  City, China and have its own factory.

  We have over 4 years of experience

  in computers and 3 years OEM partnership with worldwide famous firms.

  Proud of our production capabilities and competitive price, we are

  confident of bringing you advanced products that meet international

  standards.



  We are committed to "honesty, high quality and technology development".

  The aim of our strong R&D team is to continually develop our products in the line of the latest technological developments and meet current market trends.

  Main products

  Industrial panel pc

  1 - Industrial panel mount panel pc

  2 - Rackmount industrial panel pc

  3 - high performance industrial panel pc

  4 - Multitouch Industrial Panel PC

  Indsutrial LCD monitor

  1 - Industrial flat LCD monitor

  2 - rackmount industrial lcd monitor

  3 - open frame industrial lcd monitor

  Fanless embedded computer

  Rackmount workstation

  Mini itx d525 motherboard

  Low Power Lower Radiation?Wide Temperature
