G3 Machine Room Less Steel Belt Elevator - China

G3 machine room-less steel belt high-end passenger elevator.

Cancel the conventional machine room, improve the utilization rate of the shaft, and create more possibilities for architectural design.

With its advanced technology, high efficiency, energy saving, safety and intelligence, it creates more value for high-end residences, high-end office buildings and luxury hotels.

Technical Specifications

Capacity: 400kg~1600kg

Speed: 1.0m/s~1.75m/s

Travel: 90m

Maximum Stops: 24 floors Traction System

Energy Efficient

The diameter of the steel belt pulley is reduced to 25%-28% of the wire rope pulley, and the smaller diameter of the traction sheave provides greater torque.

Because there is no need for a gear box, the motor efficiency is improved, and the motor efficiency can reach more than 95%, achieving maximum energy saving.

Space Optimization

G3 is equipped with the latest rare earth permanent magnet synchronous gearless energy-saving host.

The volume of the machine is 70%-80% smaller than that of the ordinary machine, providing more possibilities for architectural space design.

Run Smoothly

The traction sheave of the machine adopts an arc-shaped section design, which limits the deviation or separation of the steel belt from the wheel groove, so that the elevator runs more stably.

The surface coating of the traction wheel spokes improves the wear resistance and prolongs the service life of the main engine.

Composite Steel Belt

G3 adopts the latest imported composite steel belt to replace ordinary steel wire rope.

Let passengers enjoy a high-end ride experience.

More Safer

The safety performance of the composite steel belt is much higher than that of the steel wire rope, and each steel belt can withstand a tensile force of up to 40KN.

And after more than a dozen rigorous performance tests.

More Durable

The life of composite steel bars is 2 to 3 times longer than that of traditional steel wire ropes.

More Comfortable

The flexibility of the composite steel bar is much greater than that of the steel wire rope, so the vibration generated during the elevator operation is greatly reduced, creating a quiet and comfortable elevator environment for users.
