Easy Operating Hoists Hsc Manual - China

1 - HS-C chain hoist Introduction:

HS-C chain hoist series, derived from HSZ type, is newly

designed with the advanced technology in the world.

Besides

those traditional characteristics, HS-C series chain hoist

is more labor saving and beautiful and it has higher

practicability.



2 - Features

1)Heat treated low-wear, corrosive resistant chain

2)Forged upper and lower hooks

3)Ratchet type brake warrants, safe and dependable

operation

4)Standard lift heights is 2.5-3 meters and optional lift

heights also available upon request

3 - HS-C chain hoist Parameters:

Model HS-C 1/2 HS-C1 HS-C1 1/2 HS-C2 HS-

C3 HS-C5 HS-C10 HS-C20

Capacity t 0.5 1 1.5 2 3 5

10 20

Standard lifting height m

3 3 3 3

Test load t 0.75 1.5 2.25 3 4.5 7.5

12.5 25

Min distance (hook to hook) mm 255 306 368

444 486 616 700 1000

Chain pull to lift full load N 221 304 343

314 343 383 392 392

No.

of load chain fall lines 1 1 1 2

2 2 4 8

Diameter of load chain mm 6 6 8 6

8 10 10 10

Dimensions mm A 125 147 183 147

183 215 360.5 585

B 111 163

163 191
