Frp Nitrogen Sealed Water Tank - China

FRP Nitrogen Sealed Water Tank fiberglass water storage tanks fiberglass tank for sale FRP Storage Tank Product Description

Specification: DN3500*5250

Medium: ultrapure water

FRP nitrogen sealed water tanks are generally used in ultra-pure water systems, that is, nitrogen is filled on the water surface of the water tank to maintain a proper positive pressure in the tank and prevent the atmosphere from contacting the water surface in the tank.

Generally used in mixed bed or EDI electrodeionization equipment after the need to set up a buffer tank, a nitrogen sealed water tank is used as the buffer tank.

The nitrogen sealing device is composed of two parts: a quick relief valve and a micro-pressure regulating valve.

The quick relief valve consists of a pressure controller and a single-seat shut-off valve.

The Yongchang-branded glass fiber reinforced plastic (FRP) storage tanks are well designed and manufactured according to customer demand, with various shapes, sizes and configurations.

We can manufacture storage tanks of any specification and pressure, which can be made into composite containers such as PVC/FRP, PP/FRP, PVDF/FRP according to the conditions of use.

Our designers can calculate the hoop stress, axial stress, and bending Poisson’s ratio coefficient of the product according to your available space, chemical storage requirements and applicable natural conditions, and then give the detailed manufacturing process parameters, such as product selection, product thickness, and layering.

All of our designed containers meet industry standards, such as ASTM D3299 for filament-wound storage tanks and ASTM D4097 for contact molded storage tanks.

Advantages of FRP storage tank:

(1) Light weight and high strength

The density is between 1.5~2.0, only 1/4~1/5 of carbon steel, but the tensile strength is close to or even higher than that of carbon steel

2) Good corrosion resistance

3) Good electrical performance

It is an excellent insulating material used to make insulators.

Scope of application

Media that can be stored: inorganic acids, organic acids, bases and hydroxides, elements, gases, and other inorganic compounds, alcohols, aldehydes, ketones, ethers, esters, hydrocarbons and petroleum products, halogen-containing organic compounds and other organic compounds, etc.

medium.

Company Contact:

• Posted By: Hebei Yongchang Composite Technology Co., Ltd.

• Phone: +863188615118

• Address: West of Pengcun, Jizhou Town, Jizhou District, Hengshui , Hebei , China

• Email:

• Website: https://www.yongchangfrp.com

• Business Description: Hebei Yongchang Composite Material Technology Co., Ltd. is a Chinese professional company based in the Economic Development Zone, Jizhou District, Hengshui City, Hebei Province.

  The company has introduced 6 fully automatic microcomputer-controlled filament winding production lines, covering an area of more than 50000 square meters, producing filament winding fiberglass storage tanks, pipes and other series of products.

  The products manufactured by the company have been widely used in the chemical engineering, light industry, pharmacy, metallurgy, brewing, electrochemical water supply and drainage, petroleum refining, steel-making, printing and dyeing, transportation and storage, food brewing, fermentation, water treatment, seawater desalination and other domestic and foreign industries.

  The products comply with the a series of national standards of many countries, including Chinese standard (GB), American standard (ASME), German standard (DIN), Japanese standard (JIS), etc.

  The company provides customers with the following products as well as their installation and after-sales service:

  1 - FRP storage tanks, specifically designed for producing FRP containers with a diameter of 25000mm (5000 cubic meters) or less.

  2 - Pipelines, including FRP process pipelines and FRP sand pipelines.

  3 - FRP and plastic composite products, including FPR\PP, FPR\PVC, FPR\CPVC, FPR\PVDF, etc.

  4 - FRP desulfurization devices, i.e. humidification towers, desulfurization towers, slurry tanks, thickeners, oxidation tanks, venturi tubes, flues, chimneys, spray pipelines, biogas purification and treatment facilities, etc.

  5 - Transfer of production technology of a complete set of microcomputer controlled filament winding equipment, and the relevant guidance and training.
