Pu 4648 Sync Ir Uhf Wireless Microphone - China

1 - With the UHF frequency high band, there is less

interference than the traditional one so that the

transmission is more reliable.

2 - With the PLL technology, 200 frequency channels can be

chosen, which make it convenient to use several sets at the

same time and avoid kinds of interference.

3 - Sync IR Frequency synchronization technology adopted, the

frequency of the transmitter can be received automatically

by the sync IR signal and synchronously with the receiver.

The signal is stable and the anti-interference capacity is

enhanced.

4 - The transmitter and receiver have the LCD screens, which

can display the working frequency and sync IR.

The operation

is simple, direct and convenient.

5 - Two 1.5V batteries used in the transmitter, the life of

the batteries is long so that it is convenient for the

customers to buy, maintain and change.

6 - Independent balance and unbalance mix output in the

receiver, it is convenient for all kinds of audio equipment

to connect.

7 - The working distance is more than 60 meters.

8 - Both the receiver and the transmitter are made of high

strength alloy so they are sturdy and durable.

9 - Handheld, lavalier and headset can be chosen to match

with the receiver to meet the requirement of different

occasion.

Frequency Range: UHF 620-950MHz

Frequency Response: 40Hz-18kHz

Frequency Stability: ±0.005%

Modulation Mode: wide- band FM

Modulation Range: 25MHz

Total channels: 4*100 channels

Working distance: 60m

Channel spacing: 250 KHz

Dynamic Range: 100dB

Maximum Deviation: ±45KHz

AF Response: 65Hz-15KHz (±3 dB)

Total Harmonic Distortion: ＜0.3 %

Audio Output : 0-±500mV

Receiver

Power supply: AC 100-240V, 50/60Hz

DC Adaptor output power: 13-15V, 500mA

Power consumption: 5W

S/N Ratio: ＞98dB

P/N Ratio: ＞80dB

F/N Ratio: ＞80dB

Receive sensitivity: 5dBu

Transmitter

Frequency Oscillation Mode: PLL

Transmitter Power: High 30Mw, Low 3mW

Modulation Mode: FM

Band width: 50MHz

Frequency Interval: 250KHz

Maximum Deviation: ±45kHz

Harmonics Radiation: <-55dBc

Battery Voltage: AA 1.5V×2

Battery Life: 8-10 hours
