Free Sample 1000base T Dual Port Magnetics Modules Trc5012nl - China
price: 0.78 Dollar US$
Speed: 1000Base-T
Without PoE function
SMD Type
Dual Port transformer
48Pins
Isolation voltage: 1500vrms
UL, RoHs, UL, ISO9001: 2008
Free sample available for testing
1 - Designed to support application, such as SOHO (ADSL modems), Lan-on-Motherboard(LOM), hub and switches.
2 - Meets IEEE 802.3 specification.
3 - Maximum reflow temperature is 260℃, 5 Sec.
4 - UL certification: File Number E321120
ELECTRICAL SPECIFICATION @25℃
1 - OCL:
350uH MIN @100KHz, 0.1Vrms, 8m DC Bias
2 - Turn Ratio: ±3%
TX= 1CT: 1CT RX= 1CT: 1CT
3 - Insertion Loss:
1-100MHz: -1.4dB max
4 - Return Loss(dB Min):
1-30MHz: -1.6
40MHz: -14.4
50MHz: -13.1
60-80MHz: -12
100MHz: -10
5 - Cross Talk(dB Min)
30MHz: -43.5
60MHz: -37.5
100MHz: -33
6 - DCMR(dB min):
30MHz: -45
60MHz: -40
100MHz: -35
7 - Isolation Voltage: 1500Vrms min
8 - Operating Temperature: 0 to 70℃
Company Contact:
- Posted By: Shenzhen Trxcom Electronics Co.,Ltd
- Phone: 86--13554918626
- Address: 4/F,3 BLDG,No.3 Industrial Zone,Minzhi Villiage,Longhua Town,, shenzhen , Guangdong , China
- Email:
Published date: August 23, 2016
- Business Description: Trxcom is the leading manufacturer of RJ45 connector with magnetic, Lan Transformer, Audio transformer.
The products are widely used in networking and communication equipments such as HUB, PC card, Switch, Route, PC Mainboard, SDH, PDH, IP Phone, Xdsl Modem.
1) 10/100/1000M LAN pulse transformer and filter
2) RJ45 connector with 10/100/1000M magnetic
3) T1/E1, T3/DS3/E3 - STS-1 interface line transformer
4) ISDN, HDSL, ADSL and VDSL interface line transformer and splitter
