T1 Cept Isdn Pri Transformer Trb85351nl - China
price: 1.00 Dollar US$
Single Through Hole
Single Port
6 PINS DIL
Isolation Voltage: 1500Vrms
Temperature: 0- 70 ℃
UL, RoHs, Reach, ISO9001: 2008
Free sample available for testing
1 - T1/CEPT/ISDN-PRI Transformer.
2 - With various turna ratios.
3 - RoHs"NL" peak solder rating 265℃
4 - UL Certification: File Number E321120.
Electrical Specification @25℃
1 - Turn Ratios (± 5%): Pri: Sec= 1: 2CT
2 - Primary Pins: 2-6
3 - OCL: 1.20mH min
4 - Cw/w: 40pF Max
5 - LL: 0.5uH Max
6 - DCR: (PRI) 0.7Ω, (SEC) 1.3Ω max
7 - Hi-Pot: 1500Vrms Min
8 - Operating Temperature: 0-70 ℃
Company Contact:
- Posted By: Shenzhen Trxcom Electronics Co.,Ltd
- Phone: 86--13554918626
- Address: 4/F,3 BLDG,No.3 Industrial Zone,Minzhi Villiage,Longhua Town,, shenzhen , Guangdong , China
- Email:
Published date: August 26, 2016
- Business Description: Trxcom is the leading manufacturer of RJ45 connector with magnetic, Lan Transformer, Audio transformer.
The products are widely used in networking and communication equipments such as HUB, PC card, Switch, Route, PC Mainboard, SDH, PDH, IP Phone, Xdsl Modem.
1) 10/100/1000M LAN pulse transformer and filter
2) RJ45 connector with 10/100/1000M magnetic
3) T1/E1, T3/DS3/E3 - STS-1 interface line transformer
4) ISDN, HDSL, ADSL and VDSL interface line transformer and splitter
