Panasonic CM602-L pick and place machine

If interest, feel free to contact me MODEL ID: CM602-L

MODEL NUMBER: NM-EJM8A

PCB DIMENSIONS: L 50 mm x W 50mm to L 510 mm × W 460 mm

HEAD TYPE: High-speed head (Type A-2 head, 12/12 nozzles) (OPTION) Number of nozzles: 12 nozzles Maximum speed: 0.036 s/chip (100, 000 cph) Placement accuracy: ±40um/chip Component dimensions: (01005")0402 chip*5 to L 12mm x W12mm xT6.5mm

HEAD TYPE: High-Flexibility Head (OPTION) Number of nozzles: LS 8 nozzles Maximum speed: 0.048 s/chip (75, 000 cph) Placement accuracy: ±40um/chip, ±35um/QFP≧24mm, ±50um/QFP<24mm Component dimensions: (01005")0402 chip*5 to L 32mm x W32mm xT8.5mm*8

HEAD TYPE: Multi-Functional Head (OPTION) Number of nozzles: 3 nozzles Maximum speed: 0.18 s/QFP (20, 000 cph) Placement accuracy: ±35 um/QFP Component dimensions: (0201")0603 chip to L 100mm x W 90mm xT 25mm*7

PCB EXCHANGE TIME: 0.9s (board length: up to 240mm under optimum conditions)

ELECTRIC SOURCE: 3-phase AC 200, 220, 380, 400, 420, 480V, 4.0kVA

PNEUMATIC SOURCE: 490 kPa, 170 L/min (A.N.R)

DIMENSIONS W 2, 350 mm x D 2, 290 mm *2 x H 1, 430 mm *3

MASS 3, 400 kg GOLDLAND ELECTRONIC TECHNOLOGY CO., LTD focus on global Surface Mount electronic assembly sector for 10 years.

We mainly provide competitive price and high quality products for various brands of SMT equipments, SMT feeders, SMT nozzles, SMT feeder spare parts, AI equipments, AI spare parts and other related products.

The brands is: FUJI, KEM, PANASERT, YAMAHA, JUKI, Hitachi, Universal, Siemens, I-pulse, Assembleon, DYNAPERT, TDK and so on.
