Axial High Voltage 1kv 10uf Ceramic Capacitor Low Esr X7r Y5v - China

Product features: Low loss, high capacity stability, linear change in capacitance and temperature, multiple temperature coefficients, multiple temperature levels Electrical characteristics: Technical requirements reference Standard: GB/T 2693-2001 ; GB/T 5966-1996 Rated Voltage(UR): 50 / 63 / 100 / 250 VDC Capacitance Range: 0.5pF to 10000pF, 100pF to 10000pF Withstand Voltage: 2.5UR(DC) Capacitance Tolerance: ±0.25pF(C), ±0.5 Pf(D), ±5%(J), ±10%(K ), Y5P±10%(K ) ; Y5U, Y5V±20%(M) ; Y5V+80/-20%(Z) Quality Factor (Q): C<30pF: Q≥400+20C ; C≥30pF: Q≥1000 Dissipation Factor (tgδ): tgδ≤2.5% Insulation Resistance(IR): IR≥10000MΩ Operating Temperature Range: -25℃ to +85℃ Temperature Characteristic: NPO, N750, SL, Y5P, Y5U, Y5V Flame Retardant Epoxy Resin: UL94-V0 JEC High Voltage Ceramic Capacitor Application Area : 1 - Apply to resonance circuit and temperature compensation effect circuit.

2 - Apply to bypass or coupling circuit.

Also apply to those vibration frequency circuit with not too high requirement for low frequency loss and capacitance stability performance.

Matters Needing Attention: 1 - Do not store the capacitor in corrosive gas, especially in the presence of chlorine, sulfur, acid, alkali, salt, moisture, etc.

2 - The storage temperature and the relative humidity should not be too low or too high.

Dongguan Zhixu Electronic Co., Ltd (also JYH HSU(JEC) Electronics Ltd) provides a complete range of High-Reliability capacitor and resistor models.

We’re manufacturer with our own factories so we’re able to prepare your orders within the shortest lead time as well as control the product quality.
