Cbb60 Capacitor By Polypropylene Film - China

metalized film capacitor for water pump

1 - widely for washing machine, mirco water pump, cleaning machine and high efficiency compressors of refrigerators etc.

2 - From capacitor factory

3 - SH capacitor run leader

metalized film capacitor for cleaning machine

It is widely applied to starting and running of AC single-phase motors at 50Hz(60Hz) frequency, especially for washing machine, mirco water pump, cleaning machine and high efficiency compressors of refrigerators etc.

Feature:

CBB60 capacitor takes heavy-edge metallized Al/Zn PP film as electrodes and

dielectric.

Its components are sealed with flame-retardant epoxy resin.

It has cylindrical outline with high moisture resistance and stability.

Specification:

Capacitance range: 4uF~30uF

Climate type: 40/70/21 or 40/85/21

Capacitance tolerance: ± 5%

I.

R : ≥3000S(MΩ•µ F)

Dielectric dissipation factor : tgδ≤0.002 (50Hz~100Hz)

Altitude : ≤2000m

.

Standard : IEC 60252-1: 2001

Note:

1 - Other capacitance and dimension serials can be specified in compliance with customer's request.

2 - Terminal forms can be made in conformity to the requirements of agreements with customers.

Why choose us ?

1 - As a national high-tech enterprise, we have 22 years exprience in capacitor

industry, 25 industry patents and a number of invention patents.

2 - To ensure the product quality and consistency, we have obtained the ISO 9001 quality system certificate and CQC product certificate.

3 - We have modern factories and purification plant, the world first-class production equipment and the technical team consisted of a number of experts.

More products details : www.

anhuisafe.

com

TO BE TOP MANUFACTURER IS QUR TARGET !
