Hrc 500v 690v Nh3 Ceramic Fuse Gg Base40a 50a 63a - China

Quick Details

Place of Origin:

Zhejiang, China (Mainland)

Brand Name:

Solarson

Model Number:

NH3

Usage:

Low Voltage

Breaking Capacity:

High

Safety Standards:

IEC60269, EN60269

Type:

NH3 Rated voltage:

400VAC 500VAC 690VAC

Rated current:

160A Supply Ability

Supply Ability:

100000 Piece/Pieces per Week

Packaging & Delivery

Packaging Details

carton

Port

Ningbo/Shanghai Product Details

500V 690V HRC NH3 Ceramic Fuse Base Description: Low power loss NH(NT) fuses & fuse bases for industrial protection, conform to Class GL/GG and Class aM, gR, aR.

General industrial applications or for the protection of motor circuits.

Version with voltage free metal gripping lugs for insulated fuses.

Light yellow ceramic available.

Volt: - 400V ac, 500V ac, 690V ac lr: - 120kA-400Vac lr: - 120kA-500Vac lr: -50kA-690Vac Standards Ratings: 10A, 12A, 16A, 20A, 25A, 35A, 40A, 50A, 63A, 80A, 100A, 125A, 135A, 150A, 160A

Standards: IEC60269, EN60269, GB13539
