12v Universal Ac Dc Adapters - China

12V Universal ac dc adapters, UL/CUL, FCC, PSE, CE, GS, CB, BSMI, SAA, C-TICK, 3C

certifications, ROHS , efficiency level V .

Specification details:

Maximum output power: 36W

Input voltage: 90~264Vac

Input Frequency: 47Hz~63Hz

Input Current: 1.2A

Leakage Current (max): 0.25mA

No Load Power Consumption: Less than 0.3W

Efficiency: Meet CEC

Ripple noise (max): +1% Voltage Max

Line Regulation: ±1%

Load Regulation: ±5%

Hold-Up Time: 16mS

Over Voltage Protection: 120%

Operating Temperature: 0~40°C

Storage Temperature: -20~85°C

Storage Humidity: 5%RH~95%RH

Withstand voltage: AC 3KV

Burn-In Test: 100% Full Load

MTBF: 50000Hours

Weight: 175g

Dimensions

LxWxH: 96.8x44.8x29.3 (mm) Model INPUT OUTPUT

GFP361DA-1230-1 12V 2.1A-3A

GFP361DA-1524-1 15V 1.7A-2.4A

GFP361DA-1623-1 16V 1.6A-2.3A

GFP361DA-1920-1 90-264VAC 19V 1.3A-2.0A

GFP361DA-19E20-1 (47-63Hz) 19.5V 1.3A-2A

GFP361DA-2415-1 24V 1.1A-1.5A

Market: USA, Canada, England, China, Australia, Japan

Desk-top Type

Meet CEC Regulations

ROHS Compliance

Efficiency Level V

Company Contact:

• Posted By: GME Technology Co.,Ltd

• Phone: 8675533651689

• Address: A19,Western Industrial Area,Tantou Village ,Songga, Shenzhen city, China

• Email:

• Website: https://www.chinaadapter.com

• Business Description: GME Technology Co., Ltd is a professional manufacturer of ac/dc

  switching power supply, switching power adapter, led dirver, PSU and

  chargers.

  our products have attained several safety certifications,

  such as PSE (Japan), UL, FCC (USA), GS, CE(Europe), SAA, C TICK

  (Australia), CCC (China), BSMI (Taiwan) and KC (Korea) etc .

  GME focus on maintaining quality and offering perfect after sale service , ISO9001: 2000, ISO14000 and ERP system s application to ensure us to provide safety product with not only superior quality but also competitive price for customer .

  we have the ability to develop ourselves specialties to meet client s diversity demands and ever changing markets.

  GME s overriding aim is to give our user 100% satisfaction with switching power adapters.
