Outline COL5811D HD IRD with CI slot can decode transport stream from

ASI, tuner or IP sources into audio and video signal.

With the help of

CAM module, it can decrypt the encrypted programs in the input TS.

Apart

from this function, it also can encapsulate the output TS into IP pocket

and output in UDP protocol.

User can watch the contents of the IP

outputs from decoding software on computer.

The professional IRD has full-

range of output interface ports, such as HD-SDI, SD-SDI, HDMI, YPbPr,

XLR, S/P DIF, etc., which can satisfy the professional user's needs.

Features • Factory optional for DVB-S/-S2/-T/-C, ISDB-T tuner inputs •

MPEG-2 (MP@ML&MP@HL) and MPEG-4 Part 10 ( AVC high profile level 4.1)

standards complaint and decoding • Various choice of I/O interfaces,

including ASI input/output, CVBS output, YPbPr output, HDMI output,

SD/HD output (embedded 2 pairs stereos audio), AES/EBU output, 10/100M

TS over IP input/output ( optional) • Built-in re-multiplexer (

temporarily unavailable ) • VBI TELETEX , SUBTITILE support • Caption

support • 10/100M Ethernet TS over IP I/O, UDP protocol • Unicast and

multicast support • Two CI slots, multiple programs decryption support •

NMS control support DVB-C HD IRD: Input Frequency Range: 47-862MHz

Symbol rate: 0.45-7.0MBauds Input Level: -15-20dBmV Demodulation Mode:

16/32/64/128/256 QAM DVB-S HD IRD: Input Frequency Range: 950-2150MHz

Symbol rate: 2-45Msps Signal Strength: -65- -25dBm FEC Demodulation:

1/2, 2/3, 3/4, 5/6, 7/8 QPSK DVB-T HD IRD: Input Frequency Range: 146-

862MHz Bandwidth: 8MHz (2, 6, 7MHz Optional) Input Level: -87- -20dBm

Constellations: QPSK, 16QAM, 64QAM FEC Demodulation: 1/2, 2/3, 3/4, 5/6,

7/8 DVB-S2 HD IRD: Input Frequency Range: 950-2150MHz Input Level: -65-

-25dBm Code Rate: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 Symbol ratio:

1-45Msymbols Input Impedance: 75Ω Demodulation Mode: QPSK, 8PSK

Frequency Stepping: 500 KHz ISDB-T HD IRD: Input Frequency Range:

170～230Mhz and 470～860Mhz Bandwidth: 6MHz ( 6, 8MHz

Optional) Input Level: 0～-95dBm Constellations: QPSK, 16QAM, 64QAM

Code rate 1/2, 2/3, 3/4, 5/6, 7/8 Series Specifications

DVB-CI module Descrambling procession Supporting European DVB-CSA

Smart Card interface ISO7816

Interface Card separation PCMCIA

ASI input BNC connector 1 route input;

2 routes output Input impedance 75Ω

Maximum transmitting rate 54Mbps

ASI output BNC connector 1 route input;

2 routes output Output impedance 75Ω

Maximum transmitting rate 54Mbps

Ethernet Connector RJ-45

Interface Type 10/100 Base-T

Protocols TS Over IP : UDP, NMS : UDP

Video output CVBS×1 (BNC) 576i@25 fps, 480i@29.94 fps

YPbPr×1 (BNC) 1080i@ 25 , 29.94fps

720p @ 50 59.94fps

SDI×1 (BNC) 1080i@25 , 29.94fps；720p @ 50 59.94fps

576i@25 fps480i@29.94 fps

HDMI×1 1080i@25 , 29.94fps720p @ 50 59.94fps

576i@25 fps；480i@29.94 fps

Audio output Stereo unbalanced audio BNC interface

Stereo balanced audio XLR interface

Digital audio SPDIF

General Dimensions ( L×W×H) 482mm×360mm×45mm

Approx weight 3.2kg

Power <20W(Max)

Temperature range 0~45C (Operation); -20C~80C (Storage)
