    • In Line Fiber Optic Polarizers 850nm 980nm 1064nm 1550nm - China

    price: 50.00 Dollar US$

    In Line Fiber Optic Polarizers 850nm 980nm 1064nm 1550nm

    Products Photos Catalog Line Fiber Optic Photos Catalog

    RUIK´s In-line Polarizer is designed to pass the light with the specified polarization, blocking the others.

    the function is to tranform non-polarized light into linearly polarized light need.

    Parameters Center Wavelength (nm) 1550 1310 1064 980 850

    Operating Wavelength Range (nm) ±50 ±50 ±30 ±10 ±10

    Typ.

    Insertion Loss at 23℃ (dB) 0.3 0.3 0.4 0.7 0.8

    Max.

    Insertion Loss at 23℃ (dB) 0.5 0.5 0.6 0.9 1.0 Min.

    Return Loss (dB) 50 50 50 50 50

    Typ.

    Extinction Ratio at 23℃ (dB) 30 30 30 28 28

    Min.

    Extinction Ratio at 23℃ (dB) 28 28 28 25 25

    Fiber Type for Input & Output：SM-SM or SM-PM or PM-PM

    Max.

    Optical Power(CW) (mW) 300

    Max.

    Tensile Load (N) 5

    Operating Temperature (℃) -5~+70

    Storage Temperature (℃) -40~+85


    Company Contact:


    • Phone: 18929412926

    • Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China

    • Email: Email


    Published date: April 12, 2020 - Modified date: April 12, 2020

    • Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.

      We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.

      Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.

      We also provide Customized components to our customers.

      High power Optical Fiber Components:

      - Optical Fiber Isolator, up 100W

      - Free Space Isolator, up to 100W

      - Optical Circulator, up to 30W

      - Pump Laser Protector

      - Band Pass Filter

      - Nx1 Pump Combiner

      - Cladding Power Stripper

      - Mode Field Adapter

      - (N+1)x1 Pump & Signal Combiner, 200W/port

      Polarization Maintaining Fiber Components:

      - In Line Polarizer/Depolarizer

      - In Line Faraday Isolator

      - Optical Circulator

      - Fused WDM / Coupler

      - Filter WDM / Coupler

      - Fiber DWDM

      - Fiber Mirror

      - Faraday Rotator
