Pm Optical Fiber Faraday Isolator 1064nm - China

Ruik's polarization maintaining optical isolator is a device, which allows the light to transmit through the passive route from input to output, while blocking the reversed direction.

Specifications

Parameter Unit Value

Stage - Single Dual

Grade - P A P A

Center Wavelength nm 1064

Operating Wavelength Range nm ±5

Typ.

Peak Isolation dB 40 38 55 52

Min.

Isolation at 23℃ dB 32 28 45 42

Typ.

Insertion Loss at 23℃ dB 1.5 1.6 2.4 2.6

Max.

Insertion Loss at 23℃ dB 1.8 2.2 3.2 3.4

Min.

Return Loss (input/output) dB 50/50 50/50 50/50 50/50

Max.

Polarization Dependent Loss at 23℃ dB 0.15

Max.

Optical Power(CW) mW 300

Max.

Tensile Load N 5

Operating Temperature ℃ -5~+50

Storage Temperature ℃ -40~+85 Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single-mode Fiber Components with ranging from 780nm to 2000nm.

We also provide Customized components to our customers.

High power Optical Fiber Components:

-Optical Fiber Isolator, up 100W;

-Free Space Isolator, up to 100W;

-Optical Circulator, up to 30W;

-Pump Laser Protector;

-Band Pass Filter;

-Nx1 Pump Combiner;

-Cladding Power Stripper;

-Mode Field Adapter;

-(N+1)x1 Pump & Signal Combiner, 200W/port; Polarization Maintaining Fiber Components:

-In Line Polarizer/Depolarizer;


-In Line Faraday Isolator;

-Optical Circulator;

-Fused WDM / Coupler;

-Filter WDM / Coupler;

-Fiber DWDM

-Fiber Mirror;

-Faraday Rotator;

-Fiber Patch cord / Jumper;

-PLC Splitter Module;

-Tap / WDM / Isolator Hybrid;

Manual Variable Optical Attenuator;

-1x2 Polarization Beam Splitter / Combiner (PBS/C)

-1x2 Isolator & Polarization Beam Splitter / Combiner (IPBS/C)

Company Contact:

• Posted By: Ruik-tech Communication Co., LTD

• Phone: 18929412926

• Address: Floor 4, Building A, ZhaoHe Industrial Park,, Dongguan , China , China

• Email:

• Website: https://www.ruik-tech.com

• Business Description: RUIK- Tech Communication is a manufacturer and supplier of Optical Passive Components with ISO9001: 2015 certified.

  We design advanced and cost- effective passive components for various industries which include Fiber Laser, Sensing Applications, CATV, Telecommunication, Medical Systems, Gyroscope, etc.

  Our main products include High Power Components up to 100W (20kW), Polarization Maintaining (PM) and Single- mode Fiber Components with ranging from 780nm to 2000nm.

  We also provide Customized components to our customers.
