Professional Manufacturer Economic Rgb P6 Outdoor Smd Led Module - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

outdoor SMD P6

Usage:

Outdoor

Tube Chip Color:

Full Color

Display Function:

video, image, text, message and so on

Pixels:

6mm

Screen Dimension:

Customized

Name:

rgb p6 outdoor smd led module

Other name:

Professional manufacturer rgb p6 outdoor smd led module

Certificate:

CE ROHS FCC

Brightness:

7000cd/sqm

Color:

Full-color

Led chip:

Epistar

Warranty:

2years

Application:

Live Events Led Display

Module size:

192x192mm

Viewing angle:

H140° V140°

Packaging & Delivery

Packaging Details:

rgb p6 outdoor smd led module Packing: Outdoor led screen P6: pearl wool + carton + wooden box or flight case

Delivery Detail:

Shipped in 15 days after payment

Professional manufacturer economic rgb p6 outdoor smd led module Product Description Specification of rgb p6 outdoor smd led module

No.

specs outdoor full color PH6

1 Pixel structure SMD, 3535

2 Pixel pitch 6mm 3 Pixel density 27777dots/Sq.

m.

4 Luminance 6000cd/Sq.

m.

5 Module dimension 192mm(W) * 192mm(H)

6 Module resolution 32 pixel(W) *32pixelmm(H)

7 Module weight 280g

8 Cabinet dimension 768 * 768mm or other

9 Cabinet area 0.59 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 6m

12 Visual angel 140 degree (H/V)

13 Max power consumption 1150w /Sq.

m.

14 Average power consumption 575w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/8 dynamic scan, constant current

17 Input voltage AC 110~240 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
