Vehicle Mounted Laser Night Vision Camera Shr Vlv350 - China

1 Maximum monitoring distance

- 300m at night

- 600m in the daytime

2 Day light camera

- Pixel: about 440000 pixels

- TVL: 540TVL ( color) , 570TVL ( black and white)

- Focal length: 4.1- 73.8mm, 18x optical zoom

- Aperture value: F1.4- 3.0

- Horizontal field view: 2.8°- 48°

3 Laser illuminator

- Wavelength: 810nm, 5w

- Illuminating angle: 2°- 50° synchronous continuous adjustment

4 Pan- tilt

- Speed: pan speed 0- 80°/ s, tilt speed 0- 60°/ s

- Angle: pan 360°, tilt +90° to - 90°

- Presets: maximum 128

- Cruising paths: 6 cruising paths, each path can set up to 20 presets

- Others: 40s self- checking, with power- off memory function

5 Interface

- Power supply interface: AC24V

- Other interfaces: RS485, BNC video output

6 Environmental indicators

- Working temperature: - 25 to +55°C ( - 40 to +55°C can be customized)

- Storage temperature: - 40 to +65°C

- International protection: IP65

- Anti- vibration: GB/ T 4857.10- 2005

- Anti- impact: GB/ T 15412- 94 free drop test method

- Anti- thunder: 2000V

7 Power

- Working power supply: AC24V±10% / 3A

- Power consumption: 45W

8 Physical features

- Weight: 7.5kg

- Size: 374 * 218 * 243mm
