Ce Approval Gsm 3g Smart Security And Home Automation Community Alarm - China

The K8 GSM 3G Community Alarm is an innovation security solution for

community, commercial building, Commercial Street, and Residential

areas.

If anyone panel occurs alarm then will notify neighbors

immediately.

This is very useful for SoS help and fire alarm.

The neighbors can choose what alarm to receive from neighbors' panel, and also

can forward to its neighbors

With new advanced designation, K8 supports 99 defend zones, and up to 999

event logs record for review, Big LCD display, touch keypad and 10 languages

user friendly menu for easy programming and operation.

The K8 GSM 3G Community Alarm panels can setting 10 kinds of zone types which

ensure users and assets be protected 7* 24 hours.

Users can also remote access door or garage by missed call, just dial in to

the K8, your system will change to Stay arm mode and open the door or garage

when you back home.

By the thoughtful and unique design functions, such as Schedule Arm/ Disarm,

Bypass arm, SOS alarm, elderly living care, wireless door access & remote

control, sensor' s low battery alert, Arm/ Disarm notification SMS , event

logs, etc.

K8 can do more than your imagination for your safety and smart

living whenever you are home or away.

Feature:

1) GSM Quad- Band 850/ 900/ 1800/ 1900MHz enable K8 works great in

worldwide.

3G is optional;

2) Can notify neighbors while alarm occurrence immediately or

receive specified alarm notifications from neighbors.

3) 99 zones for security intrusion alarm, elderly care, SOS help,

7* 24 hours safety applications.

4) 10 different zone types and zone name editable.

5) Multiple status optional: Stay, Away, Bypass, Schedule Arm/

Disarm.

6) User friendly menu with 10 languages: English, Spanish, French,

German, Russian, Italian, Indonesian, Czech, Danish, Bahasa, Chinese.

Vietnamese, etc.

7) Visible information on big LCD screen, easy setting and

operation by touch keypad.

8) Two way voice communications, regular phone call as hand set

supported.

9) 2 wireless switch channel for remote control & door access ( *

works with WS1, WS2) .

10) Just simply dial in to the K9, change the status to Arm / Stay /

Disarm by missed call, or create voice conversation automatically.

11) Monitoring zone for take care of elderly daily life activities.

12) Temperature monitoring alarm.

13) Wireless sensors battery low power alarm.

14) Backup rechargeable battery inside, AC power lost alert.

15) Audible alarm inside, support wireless siren too.

16) Ademco Contact ID protocol over GPRS data supported.

17) Fashion design of sleek panel with a classic elegant piano

finish.

18) Easy DIY- - Smart phone APP on Google Play for configuration &

operation.

19) Up to 999 event logs for record alarm, call in or out, etc.

Specification:

GSM/ 3G Frequency: Quad- band 850/ 900/ 1800/ 1900 MHz/ 3G Optional

Wireless Zones: 95

Radio Frequency: 433.92MHz for sensors, 315MHz for wireless switch ( *

optional)

Wired Zones: 2, NC/ NO dry contact

Tamper Switch Zone: 1, at back side of panel

Digital Output: 1 relay, NC/ NO dry contacts, 3A/ 240VAC, 5A/ 24VDC

Max.

Stored Phone No.

: 9 phone numbers for alarm SMS & call

Max.

Remote Control: 9 pcs

Event Logs: 999 alarm logs, 99 operation logs

Internal Audible Alarm: 95dB

CMS: KingCenter CMS- 01, or Contact ID CMS Supported ( GPRS data)

Rated Power Supply: 9~24V DC/ 1A

Power Consumption: 12V input Max.

270mA, Standby 30mA

SIM Card: Support 3V SIM Card

Antenna: 50 Ω SMA Antenna interface

Temperature Range: - 20~+60 °C

Humidity Range: Relative humidity 90% ( condensing free)

Backup Battery: 3.7V / 900 mAH Li- ion rechargeable

Enclosure Material: ABS plastic

Exterior Dimension: 18.8* 13.1* 2.8 cm ( 7.4* 5.1* 1.1 inch)

Net Weight: 320 g ( 0.7 lb)

Standard Package:

GSM 3G Alarm Panel * 1

Wireless PIR Motion Sensor * 1

Wireless Door Contact Sensor * 1

Remote Control * 2

AC/ DC Power adapter * 1,

User Manual * 1

Packing size: 20* 15* 9 cm ( 8* 5.8* 3.5 inch)

Gross weight: 820 g ( 1.8 lb)

Optional Accessories:

Fall detector EM- 90, SOS Panic buttons

Smoke, Gas, Water, CO detectors

Vibration, Glass breakage detector, Wireless siren SR- 03, SR- 10

Wireless switch module WS1, WS2
