1 3m 720p Hd Ir Ip Camera - China

Model # HK- HT- G213( - P)

System Embedded RTOS design, dual core 32- bit DSP( TI DAVINCI DM368F)

Pixel 1.3 Mega Pixel

Image Sensor 1/ 2.5' Progressive Scan CMOS

Min.

Illumination IR ON 0Lux

Lens HD 12mm, 4/ 6/ 8/ 12/ 16mm ( optional)

Lens interface CS

Day& Night IR- cut

Compression

Video Compression H.

264 High Profile, JPEG Screen shot

Main/ Extra Stream 720P( 1080* 720) / D1( 704* 576)

Video output bit rate 32Kbps~16Mbps

Audio Compression G.

711a


Max.

Resolution 1080* 720

Frame Rate 25fps( 1920* 1080)

Image Setting Saturation, Brightness, Contrast adjustable through Client software or web server

Network features

Storage Network storage, TF card storage( optional)

Intelligent Alarm Motion detect, Video loss, Network disconnection, IP address conflict, Storage full, Storage error

Protocol TCP/ IP, HTTP, DHCP, DNS, DDNS, PPPoE, SMTP, NTP , RTSP

Basic Reset button, Anti- flicker, Dual stream, Heartbeat, Password protection

NVR/ HVR YES

Mobile Monitor Support ( iPhone, Windows Mobile, BlackBerry, Symbian, Android)

ONVIF 2.0

Multiple Browsers FireFox, Chrome, Internet Exploerer

Interface

Communication Interface 1pc RJ45 10M/ 100M self- adaptive Ethernet interface

Video Output 1Vp- p Composite Output( 75Ω / BNC)

General parameters

Operating Condition - 10~60 °C, Humidity 90% or less( non- condensing)

Power Supply DC12V±10%

Power Consumption 6W MAX

Protection Range IP66

LED 42pcs φ 5 IR LEDs, IR distance 15M

Network Features

POE is optional

Mobile Phone Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android)

Support Multiple Browsers such as FireFox, Chrome, Internet Exploerer

Built- in Web server enables the use of a standard Web browser for viewing and management

Support dynamic IP address, LAN, Internet ( ADSL and Cable Modem)

Support protocols: RTSP/ FTP/ PPPOE/ DHCP/ DDNS/ NTP/ UPnP

ONVIF Ver.

2.0 conformance

Support whole TCP/ IP protocol

Support CVBS video output and overlying DDNS, user name, password and other info

Up to 10 viewers can directly access the camera simultaneously

Compression Features

high- density and programmable communication media processor dual core 32- bit DSP( TI DAVINCI DM368F)

H.

264 Main Profile

Up to 25 frames per second in all resolutions ranging up to 720P( 1080* 720)

Support dual stream, AVI format

Low power consuming of the DSP, suit to long time running

The encoding parameter can be adjusted dynamically ( bit rate/ frame rate/ image quality)

Support 0.1M~6Mpbs bit rate adjustable; support 1~30fps adjustable

Audio Compression: support two- way audio Bidrectional Talk, support audio and video synchronized output
