3 75va 230v 7 5v Mini Transformer For Soalr Inverter - China

Name:

3.75va 230v 7.5v Mini transformer for soalr inverter

1 - technical parameters.

Miniature Toroidal Transformer

Part No power parallal series Dimension Pin Pattern Weight

VA L* W* H( MM) MM g

GW20020 3.2 7 0.457 14 0.229 44.7* 44.7* 19.5 40.64 110

GW20021 9 0.356 18 0.178

GW20022 12 0.267 24 0.133

GW20023 15 0.213 30 0.107

GW20024 18 0.178 36 0.089

GW20025 22 0.145 44 0.073

GW20040 5 7 0.714 14 0.357 49.7* 49.7* 19.5 144

GW20041 9 0.556 18 0.278

GW20042 12 0.417 24 0.208

GW20043 15 0.333 30 0.167

GW20044 18 0.278 36 0.139

GW20045 22 0.227 44 0.114

GW20060 7 7 1.000 14 0.5 49.7* 49.7* 23.1 45.72 174

GW20061 9 0.778 18 0.389

GW20062 12 0.583 24 0.292

GW20063 15 0.467 30 0.233

GW20064 18 0.389 36 0.194

GW20065 22 0.318 44 0.159

GW20080 10 7 1.429 14 0.714 252

GW20081 9 1.111 18 0.556

GW20082 12 0.833 24 0.417

GW20083 15 0.667 30 0.333

GW20084 18 0.556 36 0.278

GW20085 22 0.455 44 0.227

GW20100 15 7 2.143 14 1.071 60.0* 60.0* 26.3 55.88 304

GW20101 9 0.667 18 0.833

GW20102 12 1.250 24 0.625

GW20103 15 1.000 30 0.5

GW20104 18 0.833 36 0.417

GW20105 22 0.682 44 0.341

GW20120 25 7 3.571 14 1.786 60.0* 60.0* 37.5 55.88 435

GW20121 9 2.778 18 1.389

GW20122 12 2.083 24 1.042

GW20123 15 1.667 30 0.833

GW20124 18 1.389 36 0.694

GW20125 22 1.136 44 0.568

2 - Raw materials have abtained VDE, UL, CE, ISO9000 approval .

we guarantee quality is the first.

Test process

1 .

No- load test ( included no- load voltage, no load current and no load loss)

2 - iInductive voltage test

3 - Load test ( load voltage and temperature rise

4 - Temperature rise test .

5 - Insulated resistance

6 - Hi- pot test

7 - Leakage indutance test

8 - resistance test

9 - Surface inspection.

3 - customized audio toroidal transformer and solar energy transformer Application:

1) .

Application:

1 - audio equipment

2 - electric control

3 - computer

4 - solar device

5 - telecommunications

6 - high- end and middle- end vedio etc

2) .

Advantages:

1 - High quality 100% copper core

2 - a full range of toroidal transformer

3 - Specially sales and technical services: 5- 10Years

4 - With 14 years' producing history in transformer induatry

5 - our company have cooperated with many customers around the world and gained good reputation at home and abroad.

3) .

Note

The above- mentioned toroidal transformer is frequently- used, we can also manufacture the products by customer design.

And the specification is for reference, if has the change further, please take the material object as the standard.

4) .

GREWIN' S Dimension :

External diameter: 40mm- 300mm, height : 13mm- 130mm, Efficiency: 75- 98%

we can design the appropriate products according to customers' requirments such as installation dimension, input and output voltage, power.

.

.

etc.

)

4 - product procedure

The following picture showed you about all finished toroidal transformer production line and package with export standard carton and strong pallets:

About us:

1 - Tianjin Grewin Technology Co.

, ltd. has always laying great emphasis on our core business philosophy ' Quality and Honesty First ' .

Due to continuous innovative research and development, our products have meet the technical standards and safety standards , which are efficient and environment- friendly.

As a professional leading and a main exporter of a wide variety of electronic components in China for many years, we adhere to new products, quality to meet the needs of you and welcome all of you to negotiate

2 - Flow chart of trading activities:

NO

Step

Days need

1

Request for quotation

1 day

2

Making quotations

3

Offer and counter offer

3 days

4

Sending and receiving samples

3- 10 days

5

Sample confirmation

6

Placing a firm order

7

Paying and receiving the down payment

1- 4 day

8

Factory production & Quality inspection

15- 20 days

9

Paying and receiving the balance

4 days

10

Delivery of goods

1 days
