Aluminum PCB Advanced Circuits Specification

Aluminum Printed Circuit Boards Contain a Thin Layer of Thermally Conductive Dielectric Material that Transfers Heat.

There are many names for these products; Aluminum clad, aluminum base, Metal clad printed Circuit Board (MCPCB), Insulated Metal Substrate(IMS or IMPCB), Thermally conductive PCBs, etc… but they all mean the same thing and perform the same way.

How Are Aluminum PCBs Made?

A thin layer of thermally conductive but electrically insulating dielectric is laminated between a metal base and a copper foil.

The copper foil is etched into the desired circuit pattern and the metal base draws heat away from this circuit through the thin dielectric.

Operating theory:

The power device surface mounting on circuit layer, it is ideally suited for the mounting of high power light emitting diodes (LEDs) easily dissipating the heat generated by power devices.

Aluminum based PCB used:

1 - Audio devices: input, output amplifiers, balanced amplifiers, audio amplifier, preamplifier, power amplifier.

etc.

2 - Power Supply: Switching Regulator, DC / AC converter, SW regulator.

3 - Telecommunications electronic equipment: high-frequency electric amplifiers, Filtering appliance, Transmitter circuit, etc.

4 - Office automation equipment: Electric motor, drives.

etc

5 - Automotive: Electronic regulator, Ignition, Power Controllers.

etc

6 - Computer: CPU board, Floppy drive, Power Device.

etc

7 - Power Modules: Converter, solid-state relay, Power Rectifier bridges, etc

8 - Lamps Lighting: with the promotion of energy-saving lamps, Aluminum base PCB, used on LED lights, begin large-scale application.

Benefits of Aluminum PCBs

Heat dissipation is dramatically superior to standard FR-4 constructions.

The dielectrics used are typically 5 to 10 times as thermally conductive as conventional epoxy-glass and a tenth of the thickness

Thermal transfer exponentially more efficient than a conventional rigid PCB.

Lower copper weights than suggested by the IPC heat-rise charts can be used.
