Col5281a Multiplexer 8 In 1 Out - China

Outline COL5281A Multiplexer (8 in 1 out) is an enhanced TS multiplexer

for digital TV broadcasting head-end system.

It can multiplex up to 8

channels ASI input MPTS into one output transport stream (MPTS).

The

multiplexer also can insert EPG (electronic program guide), CA

(conditional access), data broadcasting into output TS.

This multiplexer

has the functions of supporting auto-generation of PSI/SI information,

PID re-mapping, service filtering and PSI/SI editing.

The bit rate of

input stream can reach up to 216Mbps, while the bit rate of output

stream can reach 150Mbps.

Furthermore, the multiplexer is provided with

half size LCD display and a 100M/10M Ethernet port for network

management.

Therefore, user can easily configure the settings of the

device.

Features • Fully complying with ISO13818 and EN300468 • MPEG-2

TS re-multiplexing support • 8 ASI input ports • One multiplexing ASI

output, maximum code rate up to 150Mbps • PCR correction automatically

support • Program sorting support • SDT table reflection support •

Generating PSI/SI information • Supporting PCR correction and PID re-

reflection • extracting PSI/SI information from any route of SPTS/MTPS

inputs • Supporting the cascading connection between multiple

equipments.

• Local and Remote network management support Specifications

Input Interface ASI 8 ASI input ports Maximum

216Mbps/Route Re-multiplexing MPEG-2 input TS stream re-

multiplexing PID Remapping PCR Correction Automatically Generating

PSI/SI Table Output Interface ASI One multiplexing output ports (1X2 ASI

out, one as mirror) Ethernet port 10/100Mbps NMS Ethernet Port

Miscellaneous Dimension 45mm´482mm´360mm Environment 0~45C Operation ；-

20~80 Storage power 220VAC±10%，50Hz&# 65292;25W

Col5281a Multiplexer 8 In 1 Out
