Duct Rodder Fiberglass Rod - China

Fiberglass duct rodder & fiberglass duct rod & duct rodder cable &

conduit rodder & cable rodder description: Duct Rodders applies in tow

lead-rope through a pipe, it is auxiliary means.

Surface smooth and high

resilience, so the FRP perforator with ease passes the narrow channel.

perforator consists of two parts: the glass fiber strengthen the level,

the high-pressured low density polyethylene protective layer(smooth,

firm , can resist the adverse circumstance).

It has time-savingreducing

effort, improving efficiency, etc, And can be used for telecom cables,

cable pipe and cleaning and plastic pipe of cloths to put.

when use draws

out the FPR pole by the pulley, then with a corresponding metal joint,

penetrates in the pipeline.

When cleaning, guide-head will drive

cleaning tools to clean the pipe;When arranges the cable, you may first

leads the steel wire or the iron wire, then enters the pipe with the

steel wire or the iron wire hauling cable

Fiberglass duct rodder features&benefits:

1 - strong non-conductive fiberglass rod construction

2 - stainless steel drawing head

3 - for longer conduit runs and underground duct

4 - Rugged tubular steel reel with adjustable position.

5 - Feed device allows rod to feed out or be wound back onto reel with easy pushi or pull of rod.

6 - Duct rods/duct rodders have Many applications, not only pulling the cable but also pulling

7 - Anticorrosion , good elasticity , long working life.

Specifications

1 - Fiberglass hose is lightweight and non-conductive, Because of the extreme flexibility, it can be used as push-pull rodder .

2 - Fiberglass push pull, Fiber snake duct rodder, cable rods

3 - Fiberglass hose is lightweight and non-conductive, because of the extreme flexibility, it can be used as push-pull rodder in cable installation, and in conduit which makes it very versatile

Glass fiber rod diameter(mm) φ4.5mm/φ6mm/ 66;8mm/φ9mm/φ10 mm/φ11mm/φ12mm/ φ13mm/φ14mm/ 66;16mm

Length(m) 10m-150m

Color Yellow/red/black/blue/gre en/white

Frame(mm) 650 x 250 x 680, 1000 x 470 x 1140, 1230 x 470 x 1350

Material 75-80% E-glass fiber +High density polyethylene(outer)

Feature Add metal(copper wire, stainless steel wire)in the rod for detectable purpose

Packing Wrapped and then carton box
