Lt 8030 Cv Dmx Pwm Decoder - China

DMX-PWM DMX Decoder

DMX Decoder adopted the advanced micro-electronic control technology to convert universal DMX512/1990 digital signal to CC/CV PWM signal to drive LED, which controlled by DMX512 console, output with 256 levels of gray scale per channel.

Realize 0-100% brightness or various changing effect.

And can control single color, dupi-color, RGB/RGBW LED lights.

LT-8030 CV DMX-PWM Decoder

Input signal DMX512

Input power DC5V～DC24V

Max load current 3A ×3CH Max 9A

Max output power 45W/108W/216W(5V/12V/24V)

Gray scale level 256 levels/CH

DMX512 socket XLR-3, Green terminal

Dimming range 0~100%

Working temperature -30C～65C

Dimension L125×W52×H40mm

Package Size L135×W70×H50mm

Weight (G.

W) 300g
