Shanghai Factory Hotsale P7 62 Led Module Display Full Color - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

LEADO

Model Number:

project indoor P7.62

Usage:

Indoor

Tube Chip Color:

Full Color

Display Function:

Video

Pixels:

P7.62

Screen Dimension:

Customized Size

Name:

p7.62 led module display full color

Other name:

Shanghai factory p7.62 led module display full color

Certificate:

RoHS, CE, 3C, FCC

Module size:

244mm*244mm

Color:

1R1G1B

Pixel density:

17222 dots/sqm

Pixel configuration:

SMD 1R1G1B

Driving mode:

Constant Driving 1/16

Power Supply:

220V

Average power consumption:

300W/sqm

Packaging & Delivery

Packaging Details:

p7.62 led module display full color Packing: flight case, carton, wooden case

Delivery Detail:

Shipped in 15 days after payment

Shanghai factory hotsale p7.62 led module display full color Product Description

Specification of p7.62 led module display full color

No.

specs Indoor full color PH7.62

1 Pixel structure 1R1G1B 3in1, 3528

2 Pixel pitch 7.62mm 3 Pixel density 17222dots/Sq.

m.

4 Luminance 1500-2000cd/Sq.

m.

5 Module dimension 244mm(W) * 244mm(H)

6 Module resolution 32 pixel(W) *32pixelmm(H)

7 Module weight 520g

8 Cabinet dimension 976 * 976mm or other

9 Cabinet area 0.95 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 7.62m

12 Visual angel 140 degree (H/V)

13 Max power consumption 320w /Sq.

m.

14 Average power consumption 160w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/16 dynamic scan, constant current

17 Input voltage AC 110~240 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
