Introduction

This series of products are resilient and with large deformation, suitable for large institutional design tolerances.

Single or Double layer structure, The Double layer is reinforced with special ultra- thin fabric to increase resistance and workability of punching, strip type, Malformation designs.

Self- adhesive and never recede.

No corrosion to the Copper surface, “enviromentally friendly products”.

Features

Ultra conformable, “gel- like” modulus

Designed for low- stress applications

low hardness

Applications

Telecommunications

Computer, Between heat- generating semiconductor and a heat sink

　 unit XK- P12 XK- P15 XK- P25 XK- P30 XK- P45 XK- P50 XK- P60 XK- P80 Method

Reinforcement Carrier With ( F) or Without Fiber Hard Layer ( H) or Without Fiber 　

Inherent Surface Tack 　

Color Gray Green Yellow Light Blue Gray Red Gray light Gray visual

Thickness mm 0.3~3.0 0.3~3.0 0.3~3.0 0.5~2.0 ASTM D374

Specific Gravity g/ cm3 2.12 2.44 2.73 3.1 3.24 3.35 3.45 3.55 ASTM D792

Hardness Asker C 3~4 3~5 15~18 15~20 25~30 25~30 35~40 50 JIS K7312

　 Shore 00 25~35 30~40 40~50 40~50 45~55 45~55 50~60 80 ASTM D2240

Thermal impedance @ 0.5mm 14.5psi ℃in2/ W 0.65 0.59 0.35 0.28 0.26 0.21 0.16 0.13 ASTM D5470

Thermal Conductivity W/ mK 1.2 1.5 2.5 3 4.5 5 6 8 HOT DISK

Volume Resistivity Ωcm ASTM D257

Breakdown Voltage KV/ mm 16 16 16 15 ASTM D149

Dielectric Constant 1 5.2 5.5 6.5 7 8 8 8.5 9 ASTM D150

Application temperature ℃ 　

Tensile strength psi 14 15 13 13 23 12 10 10 ASTM D149

Elongation % 200 130 100 80 50 40 30 20 ASTM D149

Siloxane Volatiles D4~D20 % <0.005 <0.005 <0.003 <0.001 GC- FID

Flammability UL94 UL94
