280w High Tower Led Projector Light - China

280w high tower led projector light

series j led projector light

model:

zgsm-tgd280j

application

stadium | arena | golf course | tennis court | airport

key features

1 - up to 840w, max lumens is 94, 000lm.

2 - special circuit design, single leds damage won't affect others' normal work.

3 - modular design for easy installation, replacement and maintenance.

4 - mounting bracket for 360 degree adjustment.

5 - multiple lighting control options are available, e.g. dali, 1-10v.

6 - designed to last at least 100, 000 hours at l70.

7 - multiple lighting distributions are available.

specifications

model zgsm-tgd280j

led brand philips luxeon tx

driver brand inventronics euc series

norminal wattage 280w

led quantity 126 pcs

input voltage 100-240/277vac, 50/60hz

power efficiency >90%

power factor >0.95

lamp rated luminous efficiency >112lm/w

lamp rated lumen output 31360 lm (lumen tolerance +/- 5%)

color rendering index ra>70

color temperature 3000k, 4000k, 5000k or 5700k

photometric type 3045, 60 degrees

optimal operating temperature 25℃

storage temperatures -40℃~+50℃

working environment between-40c~+50c, 10%~90%rh

total harmonic distortion < 10%

lumen maintenance > 100, 000 hours -l70, @25 c (77 f)

body and shell materials stretched aluminium alloy

ip rating ip66 with test report

certification ce, rohs

optional function 1-10v dc dimming

warranty 5 years

packing details

fixture dimension 634 x 192 x 291 mm

fixture weight 14.0 kg / 30.9 lbs

packing dimension 680 x 225 x 380 mm

packing weight 15.5 kg /34.2 lbs
