Artnet Dmx Converter - China

ArtNet-DMX converter is the Ethernet Control System based on

the ArtNet protocol, used to convert the Artnet network date

package into DMX512 date, adopting high-speed ARM processor,

stable and reliable working.

Following Art-net standard

protocol, it support RJ45 network interface and standard

DMX512 output interface.

Artnet-DMX-1 can be configured in one of two ways: ArtNet

convert into DMX512, or DMX512 convert into Artnet.

Artnet-

DMX-2 has two standard DMX512 date output port, output 1024

data in total.

It is compatible with all the effects lighting control

software which support Art-net protocol, widely used in the

LED dot matrix and the stage lighting control network in

needing lots of DMX-512 data, especially for TV station

recorded scene, stage performances, entertainment and so on.

Performance Features

- Based on ArtNet protocol network data communication,

accept network DMX data;

- IP address is bound to Subnet, no need to reset, plug and

play.

- ArtNet-DMX-1 could be configured for either ArtNet-DMX512

type or DMX512- ArtNet Type.

- When configured for DMX -ArtNet type.

Data packets will

be sent over the network by broadcast Mode.

- Manage ArtNet on broadcast mode or unicast mode.

- One set DMX512 data-out for ArtNet-DMX-1, two for ArtNet-

DMX-2.

- Set different network segments to avoid multiple sets

ArtNet data interference.

- Compatible with the light software based on ArtNet

Protocol, control stage lighting and LED lighting

simultaneously.

Product parameter

Artnet-DMX-1 bidirectional converter 512 channels

Power input AC100-240V (with a power adaptor)

Input signal ArtNet/DMX512

Output signal DMX512/ArtNet

DMX channels 512 channels

working temperature -20C～65C

Dimension L120×W73×H45mm

Package Size L135×W80×H50mm

Weight (G.

W) 290g

ArtNet-DMX-2 1024 channels

Input signal ArtNet

Output signal DMX512

DMX channels 1024 channels
