Ph7 62 Mm Full Color Display For Outdoor - China

Type: PH7.62mm SMD3535;

Pixel Pitch: 7.62mm;

Dimensions ( W* H) : 244mm* 122mm;

Resolution ( W* H) : 32* 16;

Pixel Density: 512dots/ module;

Pixel Density

17222 dots/ ㎡

Brightness

>5500 cd/ m²

Viewing Distance

6- 300 m based on the pixel distance and your screen size.

Drive Mode

1/ 4 scanning Real

Viewing angle

160°H—120°V

Fram Frequency / Refresh Rate

>60Hz/ s >800 Hz/ s

Working Humidity

10% - 95%

Power Supply

220V, 380V OR 110V/ 50Hz, 60Hz

Continual Running Time

>72 Hours

Life- span ( typical use)

100, 000 Hours

Average No Failure Time

>8, 000 Hours

Working Temperature

' - 20 to +50 Celsius degree

Grey Scale

Recommend 4096 level ( software adjustable from 2bit to

16bit)

Max Power Consumption

1000 W/ SQM

Average Power Consumption

350 W/ SQM

Display Colors

64G( under 4096 level gray scale)

Control Mode

Video frequency Synchronic control

Color contrast ratio / tempreture

1800： 1

Symmetry of screen brightness

≥ 0.9 ( low brightness/ high brightness)

Surface Flatness

screen surface: +/ - 1mm, difference between modules: <1mm

Signal Interface

DVI ( S- VIDEO, CVBS, VGA, PAL/ NTSC, etc.

thru.

a video

converter)

Effective transmitting distance

Unshielded Twisted pair net line transmission distance100m,

max 130m

Multi mode optic fiber transmission distance 500m; Single

mode one 10km

Display Media

Text, Animation, Graphic, Video, etc.

system Operating Platform

WINDOWS 98, WINDOWS 2000, WINDOWS XP, WIN7
