T1 2 4g Led Touch Controller - China

Brief introductionT1 is the 2.4GHZ RF wireless synchronization/zone

dimming controller which adopts LTECH multiple global initiate

technology.

The control system consists of two parts, the RF remote

control and receiver, realize the signal synchronization on multiple

receivers, zone controlled arbitrarily (not more than 8 zones) within

effective distance, a very good solution for the LED project needs

sync/zone control wirelessly.

Can RF remote the functions of dimming, quick brightness selection and DIY and so on.

User-friendly color wheel for brightness adjustment, unique LED state light for sync change indicated, user can simply know the LED working state from distance by checking the remote

Performance Features1 - Adopt 2.4GHZ RF wireless transmission technology, which is applicable for license and patent

free worldwide.

2 - Built-in with dual core driver, make it 10 times of processing speed.

can process the wireless

data transmission in complicated and multiple levels.

3 - Advanced RF and wireless sync/zone control technology, no sync signal wire between receivers, sync capability is stable and reliable.

4 - Remote controller adopts the capacitive touch control technology on the wheel, make the dimming

more intellectualized and humanized.

5 - The remote control built-in sync-status indicator, which can show the bright status of the LED

synchronously.

6 - Color changing scene mode and preset storage function.

7 - USB charging port.

Product parameterT1 Remote Control

Input voltage DC5V built-in Lithium battery

Working current ≤30mA

Working frequency 2.4GHZ

transmitting distance 30m

Remote option Sync or zone control

Battery capacity 1000mAh

Standby time ≤6 months

Normal using time 30 days

Dimension L145×W55×H22mm

Package Size L168×W102×H28mm

Weight (G.

W) 200g

T1-5A/T2-5A Receiving controller

Power supply chosen DC CV SMPS

Input voltage DC5V-DC24V

Max current load 5A+5A Max 10A

Max output power 50W/120W/240W(5V/12V/24V)

Dimming range 5~100%

Compatible remote control work with T1/T2/T2M

remote control

Sync quantity no quantity limit

Working temperature -30C～55C

Dimension L175×W44×H30(mm)

Package size L178×W48×H33mm

Weight (G.W.) 110g
