7 Inch Digital Wireless Monitor System - China

7' digital wireless monitor

Built- in 2.4GHz Digital Wireless Receiver

Video: One/ two/ three Video; Three way wireless video inputs optional, one way wired video input optional

Voltage: DC12V~36V

MENU: OSD MENU

Language: Multi- language

Monitor with reverse polarity protect; Sunshade; Keystroke with LED blue light; With light sensor

Dimension: 176( wide) * 123( height) * 22( width) mm

Digital wireless CCD camera

Built in 2.4GHz Digital wireless transmitter

Available distance: >150m, <200m when no obstacle

IR light vision, 18pcs LED lights

Shockproof degree: 6.8G

Waterproof degree: IP68

Camera with waterproof; Shockproof; Night vision

Audio input optional

Demension: 90* 60.5* 56.5mm

Camera Specification:

Images sensors: CCD/ Sony

Power Supply（ DCV) : DC12V±1V

Effective pixels: 728* 582/ 728* 512

Electronic shutter: 1/ 60( NTSC) 1/ 50（ PAL） 1/ 10, 000second

Minimum illumination: 0.1lux

S/ N Ratio: ≥ 48dB

Resolution（ TV Line) : 520

TV System: PAL/ NTSC

lens Angle（ Deg.

） : 120°

Video output: 1.0vp- p.

75Ω

IP rating: Ip68

White Balance: Auto

AGC: Auto
