14 8v Li Ion Battery Bms For Pack - China

Protection Circuit Module Specifications For 14.8V Li- ion Battery Pack

Charging voltage DC: 16.8V 4.2V/ Cell

Balance voltage for single cell 4.20±0.025V

Balance current for single cell 84±10mA

Current consumption for single cell ≤ 20μ A

Maximal continuous Discharging current 60A

Maximal continuous Charging current 60A

Over charge detection voltage 4.25±0.025V

Over charge detection delay time 0.7S—1.3S

Over charge release voltage 4.05±0.05V

Over discharge detection voltage 2.50±0.062V

Over discharge detection delay time 14mS—26mS

Over discharge release voltage 3.0±0.1V

Over current detection voltage 0.20±0.02V

Over current detection current 130±20A

Detection delay time8ms—16ms

Release condition Cut load

Detection condition Exterior short circuit

Detection delay time 200- 500us

Release conditionCut load

Protection circuitry≤ 60mΩ

Operating Temperature Range - 40～ +85℃

Storage Temperature Range - 40～ +125℃
