Bottom Price Supreme Quality P5 Led Display Module Outdoor Smd Screen - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

outdoor SMD P5

Usage:

Outdoor

Tube Chip Color:

Full Color

Display Function:

video, animation, message, images, word and so on

Pixels:

5mm

Screen Dimension:

Customized

Name:

p5 led display module outdoor smd screen

Other name:

bottom price p5 led display module outdoor smd screen

Application:

Live Events Led Display

Color:

Full-color

Brightness:

6500cd/sqm

Certificate:

CE ROHS FCC

Product name:

Outdoor P5 SMD full color led display screen

Warranty:

2years

Module size:

160mm*160mm

Power Supply:

Meanwell

Packaging & Delivery

Packaging Details:

p5 led display module outdoor smd screen Packing: pearl wool + carton + wooden case or flight case

Delivery Detail:

Shipped in 15 days after payment

Bottom price Supreme Quality p5 led display module outdoor smd screen Product Description

Specification of p5 led display module outdoor smd screen

No.

specs outdoor full color PH5

1 Pixel structure SMD, 2727

2 Pixel pitch 5mm 3 Pixel density 40000dots/Sq.

m.

4 Luminance 6000cd/Sq.

m.

5 Module dimension 160mm(W) * 160mm(H)

6 Module resolution 32 pixel(W) *32pixelmm(H)

7 Module weight 240g

8 Cabinet dimension 800 * 800mm or other

9 Cabinet area 0.64 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 5m

12 Visual angel 140 degree (H/V)

13 Max power consumption 1800w /Sq.

m.

14 Average power consumption 900w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/8 dynamic scan, constant current

17 Input voltage AC 110~240 volts

18 Operation temperature -40° C~ +60° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental / Permanent installation available
