High Current Slip Rings Dts 38x3p120 - China

DTS- 38X3P360 slip rings is designed for passing 3 ways 360A current in

narrow space, of which the current was lead out by copper strip from

stator side and rotor side.

The shaft of slip rings is made by heat-

resisting plastic.

There is a key slot in the shaft to fix and drive the

shaft.

Silver alloy contact material was brazed welding on the beryllium

copper spring.

And the spring components are fixed on the brush holder.

Separated stator part fits for narrow space.

This slip ring can work

well in 3000RPM, based on good thermal design & heat- resisting

materials.

Feature:

1) One- piece shaft design;

2) Silver alloy contact materials;

3) High operating speed;

4) Separated design;

5) Fit for use in the working conditions of high temperature.

Technical spec:

Channels 3 rings（ for signal）

Operation Voltage 0~380VAC/ DC

Current 120A/ Ring

Operate speed 3000RPM

Contact material Precious Metal

Operate temperature - 30～ 240℃

Electric noise Max.

40m Ω

Dielectric strength 500VAC@ 50Hz, 60s

Insulation resistance 500MΩ @ 600VDC

Application:

● Rotary tables, test equipment;

● Plating line;

● High- power system;

● Cable reels;

● Weapon system.
