Fuji NXT FEEDER calibration jig for smt pick and place machine

1, the whole lean, simple, functional optimization .

And the use of high- precision 0 gap guide, to ensure positional stability , greatly improve work efficiency.

2 , accurate detection .

Reclaimer position, height , strut height can be done accurately measured.

To better grasp the quality status .

3 , the use of 12 ' color LED display, LED lighting ring , 50 times magnification CCD camera , making more compact structure, beautiful.

Effectively reducing eye fatigue, improve quality of operations .

4 , easy to operate , and can simulate the placement machine , automatic continuous observation reclaimer position , a clearer grasp FEEDER continuous operation quality , and thus more effective control of polishing material rate .

5 , you can choose a variety of models such as FUJI CP6, YAMAHA, SANYO; PANASONIC, UNIVERSAL, SONY; JUKI; SAMSUNG etc.

6, the functions and features : 1 , the precise XY axis adjustment ;

2 , the axis of the camera can be adjusted directly ;

3, built- 220V DC power supply ;

4 , black and white cross reference the cursor ;

5, automatic and step function ;

6 super bright LED display ;

7, the feeders precise control fixtures;

Uses : FEEDER calibrator for calibration of various models

Power supply : 220V

Compressed air requirements : 5kg/ cm2

Dimensions: Length 500mm * Width 350mm * height 550mm

Product Specifications: 12- inch LCD monitor coming with 50 times pixel color CCD camera
