Led Indoor Outdoor Full Color Display Screens - China

Specification of interactive led floor tile No.

specs rental indoor full color PH4.81

1 Pixel structure 1R1G1B 3in1, 2121

2 Pixel pitch 4.81mm

3 Pixel density 43000dots/Sq.

m.

4 Luminance 1200cd/Sq.

m.

5 Module dimension 250mm(W) * 250mm(H)

6 Module resolution 52 pixel(W) *52pixelmm(H)

7 Module weight 400g

8 Cabinet dimension 500 * 500mm or other

9 Cabinet area 0.25 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 5m

12 Visual angel 140 degree (H/V)

13 Max power consumption 800w /Sq.

m.

14 Average power consumption 400w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/13 dynamic scan, constant current

17 Input voltage AC 110~220 volts

18 Operation temperature -10° C~ +50° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental installation available

Company Contact:

• Posted By: Shanghai Ledlord Optoelectronice Co., Ltd.

• Phone: +86 021 60709506-820

• Address: No.5239 Beisong Rd, Songjiang district., Shanghai , Shanghai , China

• Email:

• Website: http://www.ledlord.cn

• Business Description: Shanghai Ledlord Optoelectronic Co., Ltd. is a high-tech enterprise, committed to LED display R&D, manufacturing, sales, installation, debugging, service and providing customers with a complete set of solutions and OEM services.

  With years of experience, Ledlord has been one of the most trusted led manufacturers in East China.

  In the future, Ledlord will face the global market, which has been exported to South Korea, India, Spain, Russia, Guatemala, Singapore, Turkey, the United States, etc.

  The products include advertising, bank, real-estate, stadium, exhibition hall, curtain wall, leasing and so on.

  Ledlord has professional engineering and technical R & D group, who continuously carries on product development and production process improvement, providing customers with the most competitive product.

  With the guide of business philosophy "criterion, innovation

  concentration" , Ledlord has got more than tenpatents technologies.

  Ledlord comprehensively enforces international management.

  All products have been through the high and low temperature, dust proof, waterproof and vibration test.

  Outdoor products have been reached IP66 or above standards.

  Ledlord Electronics LED display is the guarantee of industry quality and confidence, who strictly improves the Quality Management System on the basis of the quality system ISO: 9001: 2008 - Ledlord products have passed CCC, CE, FCC and RoHS certifications, which highly ensure the LED products reliable performance and customers high quality requirements.
