Tablet Candy Pressing Production Line - China

1 - it is mainly applied to the outer casing of electronics, food, daily necessities, pharmaceutical and other industrial sectors.

the material is made of stainless steel and conforms to gmp standards.

2, equipped with a transparent observation window, can clearly see the working condition of the machine and can be fully opened, easy to internal clarity and maintenance.

3, the tablet press has a large pressure, a large range of compression, can press ordinary and shaped, ring-shaped and other shapes of tablets, especially suitable for multi-variety, small batch production.

mechatronics, all controllers and adjustments are concentrated on one side of the body for easy operation.

4, equipped with pressure overload protection device to avoid machine damage.

the transmission mechanism with oil-intrusive lubrication is sealed under the body to extend the service life and avoid cross-contamination.

适用范围application

in order to meet the needs of mass production of the manufacturer, according to the different sizes and yields of the tablets, it is a single-pressure automatic rotary continuous tableting machine developed by our company.

he presses the granular raw materials into various ordinary ones.

type and shaped pieces.

main technical parameter

model htl-15d punch quantity (sets) 15 max.

tablet pressure (kn) 80 max.

tablet diameter (mm) 25 : max.

filling depth (mm) 15 max.

tablet thickness(mm) 6 capacity(pcs/h) 35000 turret rotary(r/min) 35 motor power (kw) 3/960r, 380v/50hz overall size(mm) 615 x 890 x 1415 weight (kg) 1000
