Laser Cutting Machine For Metal Sheets - China

Shear Line Technical features Model：MHTS-1300M

Maximum Width(mm)：1300-2500

Maximum Thickness(mm)：3/6/10


Roller Diameter(mm)：60/80/120

Leveling Accuracy(mm/m2)：0.5

Maximum Weight(t) ：5/10/15/20

Automatic Hydraulic Feeding Trolley：Yes

Speed(m/min)：0-20


Inner Diameter(mm)：∮508- ∮610

Maximum Outer Diameter(mm)：Φ1500

Numbers of Roller：15

Controller：Semi-auto matic

Feeding Accuracy(mm)：±0.2

Air Pressure(kg/cm²)：5

Rack expansion mode：Hydraulic

Servo Motor：Servo + Reducer

Rack motor(kw)：5

Feeding direction：left→right

Feed line height(mm)：850±50

Voltage(v)：AC380v


Optional 1 - Blanking manipulator 2 - Blanking joint robot 3 - Automatic film laminating machine 4 - Automatic stacking lifting table 5 - Blanking platform

Company Contact:

• Posted By: Guangdong Dayongsheng Technology Co., Ltd.

• Phone: 13827206784

• Address: Building 3, Jiaying 1st Street ,ShiJie Town, Dongguan , Guangdong , China

• Email:

• Website: https://mhtmachine.com/

• Business Description: Guangdong ( Jiangxi) Mahatma Technology Co., Ltd. —— A high-tech enterprise dedicated to R&D, production and sales of high - precision leveling machines and supporting peripheral equipment .

  Introduce German and Swiss precision leveling / straightening equipment technology , and cooperate with many universities and research institutes in production, learning, and research to continuously carry out technological innovation and production improvement, and combine the needs of many metal precision parts manufacturing enterprises to adopt innovation Design ideas , advanced manufacturing technology , R&D and production : servo CNC high - precision leveling machine , hydraulic high - precision leveling machine , four ( six ) heavy - duty leveling machine, automatic loading and unloading manipulator , robot , laser leveling detector, High - precision uncoiling, leveling, stamping and shearing line and l aser cutting and other automatic production lines.
