600mm Track Guage Cjy10 Ton Underground Trolley Locomotive - China

600mm Track Guage CJY10 ton Underground Trolley Locomotive

Trolley electric locomotive is a kind of rail transportation traction equipment, powered by transformers and overhead lines.

Mainly used in mines where there is no risk of explosion.

Because of its special power supply mode, the trolley electric locomotive has no limit on the cruising range.

Therefore, it is suitable for long-term and long-distance use.

There are also many options in terms of speed regulation and braking methods.

Speed control methods include resistance speed control, chopping speed control and frequency conversion speed control.

Braking methods include pure mechanical braking, hydraulic braking and compressed air braking.

In addition, electric braking can also be selected as an auxiliary braking method.

Adhesive weight (t) : 10 ton

Track gauge (mm) : 500.600, 762 or 900

Traction (KN) : 13.05kN~18.93kN

Max.

Traction (KN) : 24.5kN

Speed(km/h) : 11

Voltage : 250V or 550V

Power (KW) : 24kw *2 or 30 kw*2

Dimensions

Length(mm) : 4550

Width(mm) : 1050, 1212, 1350

Height(mm) : 1600mm

Wheelbase (mm) : 1100, 1220 mm

Min Curve radius (m) : 7, 10 m

Wheel diameter (mm) : Φ680mm

Controller : Resistance or IGBT or AC controller

Braking method : Mechanical or air Brake
