Cjy 3 Ton Underground Trolley Electric Locomotive - China

CJY 3 Ton Underground Trolley Electric Locomotive Maintenance Requirements for Mining Electric Locomotives Mining electric locomotives require regular maintenance to ensure their performance and reliability.

This includes periodic inspections of the locomotive's mechanical components, electrical systems, and control devices, timely replacement of worn parts, and lubrication and cleaning tasks.

Good maintenance practices can extend the locomotive's service life and reduce the likelihood of breakdowns.

The maintenance process begins with a comprehensive inspection of the locomotive, identifying any signs of wear, damage, or malfunction.

Mechanical parts such as bearings, gears, and axles are checked for proper functioning, and any abnormalities are promptly addressed.

Similarly, the electrical system is carefully examined, including the wiring, batteries, and electronic components, to ensure optimal performance.

Regular lubrication of critical moving parts is crucial to reduce friction and prevent excessive wear.

It also helps maintain efficient operation and enhances overall longevity.

Additionally, keeping the locomotive clean from dirt, debris, and contaminants is vital to safeguard its components and ensure smooth functioning.

Incorporating a maintenance schedule that aligns with the locomotive's usage and working conditions is essential.

Routine maintenance tasks should be performed at specified intervals, and any issues detected during inspections should be addressed promptly to prevent further damage.

Overall, adhering to a comprehensive maintenance regime will not only prolong the lifespan of mining electric locomotives but also contribute to safe and efficient mining operations.

Investing in regular maintenance ensures that the locomotives remain dependable assets, delivering consistent performance throughout their operational life.

Adhesive / total weight (t) : 3 ton

Track gauge (mm) : 500.600, 762 or 900

Traction (KN) : 6.1kN/ 5.74kN

Max.

Traction (KN) : 7.36kN

Speed(km/h) : 10.6km/h/ 7.5km/h

Voltage : 250 or 550V

Power (KW) : 6.5*2 or 12*1

Dimensions Length(mm) : 2700mm/ 2750mm

Width(mm) : 940, 1082 or 1220mm

Height(mm) : 1550

Wheelbase (mm) : 816mm/ 850 mm

Wheel diameter (mm) : Φ650mm/ Φ520 mm

Min Curve radius (m) : 5.7-6 m

Controller : Resistance or IGBT

Braking method : Mechanical or Hydraulic Brake
