Temperature Control Switch Probe - China

Dry reed temperature switch make use of thermal magnetic temperature

control materials near magnetic permeability of the rapid changes to

control the reed switch open or close, it is final to achieve the

purpose of temperature control.

With thermal soft magnetic materials dry

made into reed switches and sensor has high sensitivity, high precision

temperature control, stable performance, product oxidation resistance,

corrosion resistance, not easy ageing and security excellent features.

Dry reed temperature control switch is applicable to the refrigerator

defrosting, cooling and heat preservation, auto cold boot, hot start and

cold water temperature control, cooling water system of temperature

control, all kinds of printing ink and cold control, temperature control

for baby care electrical appliance, various heating equipment

temperature control and alarm.

Technology parameters of magnetic temperature control switch

Action temperature (optional)

3C, 5C, 8C, 11C, 17C, 18C, 22C, 30C, 40C, 60C, 67C, 70C, 78C, 82C, 88C, 90C, 98C, 102C, 108C, 127C  2C

Maximum switch power 70W 10W

Maximum switching voltage 200Vdc / 240Vac 200Vdc / 140Vac

Maximum switch current 0.5A 0.5A

Maximum load current 1.0A 0.5A

Minimum switch breakdown voltage 400V 250V

Most contact resistance 200 m 120 m

Electrical life 1 x 106

Shell material SUS304, SUS316

Wire specifications UL1332 AWG24

Typical type and size are as follows: (other shape dimension can be customized)

Temperature Control Switch Probe
