Board Bursting Strength Tester - China

BNP- 01 is a new type testing instruments for the bursting strength of

corrugated boards, which is designed in accordance with ISO2759 ' Board-

Determination of bursting strength' .

Principle:

A test piece, placed over a circular elastic diaphragm, is rigidly clamped at the periphery but free to bulge with the diaphragm.

Hydraulic fluid is pumped at a constant rate, bulging the diaphram until the test piece rutures.

The bursting strength of the test piece is the maxium value of the applied hydraulic pressure.

Technical features

 LCD display and PVC operation panel

 Automatic test process, automatic bursting judgment

 Microcomputer real time data collection and data memory

 Micro printing

 Synchronous motor drive for stable and precise pressure output

Technical data

Measuring Range: 150~6000kpa

Accuracy: + / - 0.5% or less( ≤±0.5% )

Resolution: 0.01 kpa

Deformation Error: 1 mm or less

Plates Concentricity: 0.25 mm or less( ≤0.25mm)

Diaphragm resistance : bulge height 10mm/ ( 170～220) kPa, bulge height 18mm/ ( 250～350) kPa

Transmit hydraulic volume: 175±5ml/ min

Pressure Plate Diameter: upper: 31.5±0.5mm, lower: 31.5±0.5mm

Display: 4.0 in.

LCD with curve display

Clamping Force: ≥690kpa ( adjustable)

Unit Conversion: Kg/ cm2, kpa, LBF/ in2

Dimension: 360* 420* 510mm

Weight: 55KG

Standards

ISO2759, GB1539, GB/ T6545

Configuration

Mainframe, glycerinum, micro printer, calibration sheet, diaphragm
