Digital Gloss Meter Gm 268 - China

GM-268

Widely used in Floor maintenance, Surface cleaning quality control, Stone and tile gloss measurement, Checking printed matter, Quality control of paint and ink, Polished metal surface , measurement (chrome plating), Inspection of paint protection and waxing, Auto-body paint inspection, Surface inspection

of plastic moldings, Evaluation of detergents and washers, Checking masonry and washers, Checking building exteriors.

Model No: GM-268（optional : GM-6, GM-26)

TECHNICAL SPECIFICATIONS

Display: 4 digits backlit LCD

Measuring geometry: 20/60/85 Degrees (GM-6 60Degrees，GM26 20Degrees and 60Degrees)

Range: 0.1 to 200 gloss units

Accuracy: ±1.0 gloss unit

( against reference standard )

Resolution: 0.1 gloss unit

Repeatability: ±0.5 GU(0 .

99.9)

Measuring area: mm ellipse

Data memorized: groups

Data output: RS 232 C serial interface

Power supply: battery: 4×1.5VAAA

Dimensions:

main unit: 156 x67x28mm

Separate sensor: 58x28x108mm

Weight: about 305g ( including fitted batteries )

Working condition:

Temperature range 0 - 40℃

Humidity up to 85%

there are three models of gloss meter GM-268, GM-026, GM-06
