Gd 11143 Lubricating Oil Rust Characteristics Tester - China

Purpose:

The instrument is designed and made as per the National

Standard GB/ T11143 “Test Methods for Rust- Preventing

Characteristics of Inhibited Mineral Oil in the Presence of

Water”, ASTM D665, and IP135 - It is suitable to determine

rust- preventing characteristics of inhibited mineral oil,

especially the rust- preventing characteristics of turbine

oil to iron parts in the presence of water.

It is also

suitable to determine rust- preventing characteristics of

other oils, such as hydraulic pressure oil, circulation oil,

as well as liquids heavier, whose gravity is greater than

water.

The instrument has function of temperature

controlling, timing, and alarming.

Working condition

1 - The instrument should be placed on a flat and stable

workbench.

2 - Combustible materials will be involved during a test, so

please keep the instrument away from any flame ( or spark)

during operation

Technical parameters

1 - Power supply: 220 V±10% , 50 Hz;

2 - Temperature controlling range: 0～ 100℃ ;

3 - Temperature controlling accuracy: ±1℃ ;

4 - Temperature sensor: Industrial platinum resistance,

Pt100;

5 - Temperature display mode: digitally displayed;

6 - Timing range: 1 min to 24 hours;

7 - Time display mode: digitally displayed;

8 - Heating power for temperature controlling: 600 W;

9 - Heating power for auxiliary heating: 1000 W;

10 - Speed of stirring motor: 1400 RPM;

11 - Speed for sample stirring: 1000±50 RPM;

12 - Sample hole: 4 pieces;

13 - Ambient temperature: room temperature~ 35℃ ;

14 - Relative humidity: ≤ 85％ ;

15 - Total power consumption: not more than 1800 W;
