GD- 261- 1 Semi- auto ASTM D93 Closed Cup Flash Point Tester

Summary:

This instrument is designed and manufactured as per standards GB/ T 261- 2008 Determination of Flash Point - Pensky- Martens closed cup method and ASTM D93 Standard Test Methods for Flash Point by Pensky- Martens Closed Cup Tester.

It is used to make determination of the closed cup flash point of the petroleum products.

Main Technical Specifications:

Power supply: AC( 220+/ - 10% ) V, 50Hz.

Heating device:

( 1) The furnace is silicon carbide material.

Power is 600W.

( 2) The heating power is adjustable from 0 W to 600W.

Heating rate: Procedure A: ( 5~6) C/ min

Procedure B : ( 1~6) C/ min

Automatically controlled

Stirring device: ( 1) Stirring motor: BYGH101 stepping motor

Driving mode: flexible shaft

Shaft size: 8mm* 40mm

Stirring rate: Procedure A: ( 90~120) RPM, Procedure B: ( 250+/ - 10) RPM

Igniting device:

Igniting source: gas( or other civilian fuels, the same below

Electric ignition.

Gas flame diameter: 2mm~8mm

Temperature testing probe: PT100

Ambient temperature: <= 35C

Relative humidity: <= 85%

Maximum power consumption: 650W
